CHECKING FOR BLOCKAGES
MAINTENANCE
NOTE: To order replacement parts and filters, visit sharkclean.eu.
1. Using a coin, turn locks anti-clockwise to open,
then lift o cover to access Brushroll.
2. Use scissors to cut along the groove in the
Brushroll to remove any string, hair or debris
taking care not to cut the brushroll bristles.
3. Check for blockages in Debris Intake.
4. Replace cover and turn locks clockwise to close.
1. Slide Eject Roller button forward.
2. To remove Soft Roller, pull the tab on the right.
3. Tap loose debris o the Soft Roller. Use a dry
towel to wipe clean, or to remove any hair or
fibres caught in the teeth behind the Soft Roller.
4. Rinse as needed. Use O NLY lukewarm water,
and leave to air-dry completely for at least
24 hours.
5. When dry, insert the left end of the roller first,
then push the right end into place with the
word Front facing forward.
BRUSHROLL SOFT ROLLER
CLEANING OR REPLACING BRUSHROLLS
MAINTENANCE
Detach hose from vacuum pod,
and check opening on back of
pod for blockages.
Detach wand from floor nozzle
and handle, and check both
ends of wand for blockages.
Detach handle from wand and
hose from the vacuum pod, and
check openings for blockages.
Detach dust cup from vacuum
pod. Empty dust cup, remove
debris from lint screen, and
check for blockages.
Detach wand from floor nozzle,
tilt nozzle neck back, and check
opening for blockages.
NOTE: Turn off vacuum and remove battery before checking for blockages
IMPORTANT:
DO NOT use sharp or metal objects to clear blockages.
12
11
