4 TOLL FREE: 1-800-798-7398
FIRST THING’S FIRST, YOU
NEED TO KNOW WHAT’S IN THE
BOX YOU JUST OPENED:
A Vacuum Body
B Floor Power Nozzle
C Handle Assembly
D Super Stretch Hose
E Cleaning Wand
F Pet Upholstery Tool
G Cleaning Attachments
Getting Started
Your Shark
®
Navigator
™
Upright is easy to assemble:
1 Lay your vacuum body on a
level surface.
2 Slide the electrical connection
from the power nozzle into the
main body to click into place.
3 Connect the hose from the main
body to the power nozzle; push
with a slight turning motion to
create a snug fit.
4 Slide the handle assembly
into the upright unit aligning
the hose hook on the handle
assembly with the power cord
hooks on the back of the unit.
5 Secure the handle assembly in
place with included nut/bolt
(shipped attached to handle
assembly).
6 Place the vacuum in the upright
position.
7 Store the Crevice Tool, Dusting
Brush and Cleaning Wand on
the unit.
7
4
2
3
A
C
E
G
B
F
D
5
