SHARK TRAILER SERVICE MANUAL • 9.801-302.0 • Rev. 4/14
11
TRAILER
SERVICE MANUAL
ITEM PART NO. DESCRIPTION QTY
1 8.912-404.0 Frame, Assy (3500) 1
2 8.912-405.0 Fender, Single, Assy 2
3 8.707-500.0 Axle, 3500 lb. 64" Track 1
8.707-501.0 Axle, 3500 lbs, 64 Track,
Elec. Brakes 1
8.707-502.0 Axle, 3500 lbs, 64 Track,
Hyd. Brakes 1
4 8.753-334.0 Springs, Leaf, 3500 lb./Pr 1
5 8.725-529.0 Wheel/Tire Assy, 15" Wheel 2
6 8.707-497.0 Chain, 5/16 Zinc Plated 6 ft.
9.802-724.0 s Bolt, 3/8" x 1-1/2", NC,
HH, SS 2
8.718-988.0 s Washer, 7/16" Flat, SAE 2
9.802-811.0 s Washer, 3/8" x 1-1/2",
Fender 4
8.719-024.0 s Washer, 3/8", SS, Lock 2
8.719-089.0 s Nut, 3/8" HEX, NC, SS 2
7 8.707-498.0 s Hook "S" 5/16 Zinc 2
8 8.707-485.0 Jack,
Swivel/W/Caster 1500 lb.
1
9 8.707-512.0 Lamp, Stop/Tail/Turn, Red 2
10 8.707-513.0 Lamp, License W/Holder 1
11 8.707-510.0 s Connector, 7 Prong 1
12 8.707-524.0 Tank, 200 Gal, HDPE Const 1
13 8.707-526.0 Strainer, D1" T Line 1
14 8.706-376.0 Elbow, 1" PVC 80 1
15 8.706-424.0 Nipple, 1.5" Close PVC 80 2
16 8.706-439.0 Nipple, 1" Close PVC 80 2
17 8.706-484.0 Bulkhead, 1" Poly Pro 1
18 8.706-490.0 Bulkhead, 1-1/2" Poly Pro 1
19 8.706-512.0 Float, Ball, Black Plastic 1
20 9.803-557.0 Elbow, 3/4" x 3/4" 90° 4
21 8.706-899.0 Nipple, 3/4 JIC x 3/4" Pipe 4
22 8.706-929.0 Bushing 1" x 3/4" 7
23 9.802-152.0 Swivel, 3/4" SAE Fem
Push-On 10
(Garden Hose Reel Option) 12
24 8.707-025.0 Stem, Float 10" 1
25 8.749-329.0 Valve, 3/4" Plastic Float 1
26 8.707-342.0 Valve, 1-1/2" Ball, Poly 1
27 8.918-206.0 Hose, 3/8 x 125", 2 Wire
Swivel x Swivel 1
28 9.802-261.0 Hose, 3/4", Push-On 12.5 ft.
29 8.706-928.0 Bushing,
1" x 1/2", Poly
1
30 9.802-131.0 Elbow, 1/2" JIC x 1/2" 1
31 8.706-375.0 Elbow, 1-1/2"FT x FT 1
32 8.706-925.0 Bushing, 3/4" x 1/2" Pipe 1
ITEM PART NO. DESCRIPTION QTY
33 8.706-829.0 Elbow, 1/2" Street Brass 1
34 9.802-146.0 Swivel, 1/2" MP x 3/4" W/S 1
35 8.711-788.0 Hose, 3/4" Suction,
Push-On 15.33 ft.
36 8.706-917.0 Bushing, 1/2" x 3/8" Brass 1
37 8.706-968.0 Fitting, 3/4", Garden,
HS x 1/2" 1
38 9.802-132.0 Elbow, 3/4"JIC x 1/2" 2
39 9.802-041.0 Elbow, 3/8" Street, 45° 1
40 9.802-147.0 Swivel, 3/8" MP x 3/4"
GHF W/S 1
41 9.802-767.0 Screw, 3/8" x 3/4" NC
Whiz Loc 12
42 9.802-781.0 Nut, 3/8", NC, Whiz Loc 12
43 9.802-206.0 s Clamp, Hose 1
44 9.802-794.0 s Nut, Cage, 1/4" x 12 GA 8
45 9.807-349.0 Label, Clear lexan 1
46 9.802-166.0 Coupler, 3/8" Female, Brass 1
47 8.912-403.0 Bracket, Breakaway 1
48 8.706-167.0 Elbow, 3/8" FNPT 1
49 8.730-379.0 Nipple, 3/8" x 3"Pipe 1
50 8.706-294.0 Bushing, 1/2" x 3/8" Steel 1
51 8.707-506.0 Break Away Kit,
W/Battery 1
52 9.802-064.0 s Grommet, Rubber,
Nozzle Holder 6
53 8.900-522.0 s Label, CLP Warning,
Do Not Stand or Step 2
54 9.802-052.0 Bulkhead, 3/4" Poly Pro 1
55 8.706-117.0 Nipple, 1" Pipe, Close 2
56 9.802-132.0 Elbow, 3/4" JIC x 1/2" 90° 2
57 8.912-399.0 Cover, Light Bracket 2
58 8.912-398.0 Bracket, Light Tail 2
59 8.706-207.0 Elbow, 3/8" Street 1
60 8.707-230.0 Valve, 3 Way Brass 1" 2
61 9.802-171.0 Nipple, 3/8" x 3/8" Male 2
62 8.706-992.0 Adapter, 1/2" x 3/8" 1
63 8.749-879.0 Adhesive, 10" Roll, 2.5" x 7" 1
64 Vin Plate 1
65 9.802-730.0 Bolt, 3/8" x 2-1/2" GR5 Zinc 2
66 9.802-807.0 Washer, 3/8", SAE, Flat Zinc 4
67 9.802-779.0 Nut, 3/8", ESNA, NC 2
68 8.916-826.0 Guard, Exhaust, Trailer
(Super Skid Models Only) 1
69 9,802-799.0 Screw, # 14 x 1" TEK
(Super Skid Models Only) 4
s Not Shown
EXPLODED VIEW PARTS LIST — TRS-3500
