SHARK TRAILER SERVICE MANUAL • 9.801-302.0 • Rev. 4/14
5
TRAILER
SERVICE MANUAL
TRS-2500 TRAILER EXPLODED VIEW PARTS LIST
ITEM PART # DESCRIPTION QTY
1 8.917-302.0 Wlmt, Frame, Trailer, 3000# 1
2 8.917-303.0 Wlmt, Tongue, Hinged 1
8.917-535.0 Wlmt, Tongue, Hinged,
Hydraulic Coupler 1
3 8.917-304.0
Fender, w/Back, 15", Painted
2
4 8.917-305.0 Wlmt, Hoop, Hose Reel 1
5 8.725-543.0 Rod, Tie-down, Tank 1
6 8.917-325.0 Bracket, Skid Mount, Adj. 2
7 8.917-326.0 Channel, Skid Mount, Adj. 1
8 8.917-341.0 Bar, Tank Tie-down 1
9 8.725-525.0 Tank, Water, 200 Gal 1
8.704-744.0 s Lid, 8" Threaded
w/Air Breather 1
10 8.725-534.0
Jack, Swivel w/Caster,1000 lb
1
11 8.725-529.0 Wheel/Tire Assy, 15"
ST205/75d15 TI 2
12 8.725-530.0 Lamp, Tail, 3-Way 2
13 8.725-531.0 Lamp, Side Marker, Red 2
14 8.725-532.0 Lamp, Side Marker, Amber 2
15 8.725-533.0 Lamp, License w/holder 1
16 8.707-497.0 Chain, 5/16 Zinc Plated
2 x 45" Long 7.5 ft
17 8.725-536.0 Connector, Socket, 4-Flat 1
8.707-510.0 Connector, Socket, 7-Prong
(Electric Brakes) 1
18 8.725-537.0 Plug, 4-Flat 1
8.707-511.0 Plug, 7-Prong
(Electric Brakes) 1
19 8.725-538.0 Axle, 3500 lb., 57", Idler 1
8.725-540.0 Axle, 3500 lb., 57" Electric
Brakes 1
8.725-539.0 Axle, 3500 lb., 57"
Hydraulic Brakes 1
20 8.706-412.0 Bushing, 1" x 3/4" MT x FT,
PVC 80 Speers O 3
21 9.802-132.0 Elbow, 3/4" JIC x 1/2", 90° 1
22 8.707-498.0 Hook, "S", 5/16" Zinc Plated 2
23 8.707-526.0 Strainer, 1" T Line, Trailers 1
24 9.802-798.0 Screw, #10 x 1/2" Tek
Hex Head" 2
25 8.719-946.0 Hanger, Hose 2
26 9.802-052.0 Bulkhead, 3/4" Polypro 3
27 9.802-146.0 Swivel, 1/2" MP x 3/4" GHF
w/Strainer 1
28 9.802-152.0 Swivel, 3/4" SAE Fem,
Push-on" 4
29 9.802-261.0 Hose 3/4", Push-on 24"
30 9.802-701.0 Bolt, 1/4" x 1" Hex Head
Zinc Grade 3
(Break Away) 6
31 9.802-722.0 Bolt, 3/8" x 1-1/4", NC HH 34
ITEM PART # DESCRIPTION QTY
32 9.802-773.0 Nut, 1/4-20 ESNA NC 5
(Break Away) 8
33 9.802-779.0 Nut 3/8" 42
34 9.802-802.0 Washer, 1/4" Flat SAE Zinc 12
(Break Away) 14
35 9.802-807.0 Washer, 3/8" Flat 72
36 9.802-812.0 Washer, 3/8" x 1-1/2",
Fender, SAE 14
37 8.706-738.0 Plug, 3/4", Hole 2
38 8.706-899.0 Nipple, 3/4" JIC x 3/4" Pipe 2
39 9.802-724.0
Bolt, 3/8" x 1-1/2", NC, HH, SS
2
40 8.900-522.0 Label, CLP Warning, Do Not
Stand or Step 2
41 9.802-780.0 N
ut, 3/8" Stainless, ESNA, NC
2
42 8.706-731.0 Bushing, 3/4" Snap Heyco 7
43 8.706-369.0 Nipple, 3/4", PVC 80, Close 1
44 8.710-036.0 Float Valve 1" Hudson 150d
130 PSI 1
45 8.718-592.0 Screw, 1/4" x 1-1/4" Shdr 1
46 8.719-079.0
Knob, Black Plastic,10-24 Thds
1
47 8.719-112.0 Spring, 0.31OD x 1.0, Steel,
Gen Wire J-1450 1
48 8.917-463.0 Latch, Wand Holder 1
49 8.917-319.0 Bracket, Alignment, Tank 2
50 8.706-395.0 Plug, 2", PVC 80 1
51 8.706-294.0 Bushing, 1/2" x 3/8", Steel 1
52 9.802-171.0 Nipple, 3/8" x 3/8" NPT ST 1
53 9.803-557.0 Elbow, 3/4 JIC x 3/4 2
54 8.725-541.0 s Hydraulic Line Kit
(Hydraulic Brakes) 1
55 8.725-707.0 s Bolt, 1/2" x 4-1/2" Grade 5
(Hydraulic Brakes) 2
56 8.718-829.0 s Nut, 1/2" ESNA
(Hydraulic Brakes) 2
57 9.802-809.0 s Washer, 1/2" SAE
(Hydraulic Brakes) 4
58 8.912-403.0 s Bracket, Break Away
(Break Away) 1
59 8.707-480.0 s Coupler, 2" Hydraulic Actuator
(Hydraulic Brakes) 1
60 9.802-261.0 Hose, 3/4 Push-on 51"
61 8.706-890.0 Elbow, 1/2" JIC x 3/4" 1
62 8.917-328.0 Plate, Shark SS 1
62 8.718-607.0 Bolt, Carriage 1/4-20 x 3/4 2
63 8.706-397.0 Plug, 3/4 1
64 8.726-136.0 Hook, Latching 2
65 8.917-340.0 Bracket, Shipping 2
66 8.752-041.0 Grommet, Light, 2" 4
67 8.900-870.0 Label, Shark Logo 2
s Not Shown
