Page #64 background imageLoading...
Page #64 background image
18
APRON ASSEMBLY
Item No.
Part Name
Amt. Used
Type: 16
Part No.
Type: 18
Part No.
38
Key-square , 6x6x12L
1
39
Gear
1
1210903200
1210903200
40
Seat-worm
1
1210903308
1210903308
41
Shaft-worm
1
1210903406
1210903406
42
Bearing-thrust , 2904
2
91311005
91311005
43
Worm gear
1
1210902007
1210902007
44
Washer-lock , 20
1
45
Nut
1
46
Hexagon socket screw ,
M6xP1.0x12L
8
47
Spring, Ø 1x10x60L (right)
1
1210905400
1210905400
(left)
1
1210905508
1210905508
48
Block-safe device (right)
1
1210901000
1210901000
(left)
1
1210900905
1210900905
49
Pin, 5x18L
2
50
Pin
1
51
Shaft-auto feed
(right)
1
1210901206
1210901206
(left)
1
1210901108
1210901108
52
Collar (right)
1
1210901206
1210901206
53
Ring-O , P16
2
54
Cover
1
1210903602
1210903602
55
Hub (right)
1
121090141
121090141
(left)
1
1210901304
1210901304
56
Spring washer , M8
1
57
Hexagon socket screw ,
M8xP1.25x12L
1
58
Snap ring, S10
1
59
Lever
1
1210903700
1210903700
60
Spring washer, M12
1
61
Screw
1
62
Hexagon socket screw ,
M5xP0.8x20L
1
63
Spring
1
1210905606
1210905606
64
Spacer
1
1210903906
1210903906
65
Bearing ball, 6005V
1
91301012
91301012
66
Worm-wheel
1
1210902105
1210902105
67
Wheel-friction
1
1210902203
1210902203
68
Key-square, 7x7x12L
1
69
Shaft-worm wheel
1
1210904001
1210904001
70
Pin
1
1210904109
1210904109
71
Spring, compressing
1
1210905302
1210905302
72
Washer
1
1210904207
1210904207
73
Set screw
1
74
Bearing-ball , 6204
1
91301018
91301018
75
Cover
1
1210904305
1210904305
76
Snap ring , S20
2
77
Gear
1
1210902301
1210902301
78
Shaft-cross feed
1
1210904403
1210904403
