Sharp 16 Series User Manual

19
APRON ASSEMBLY
Item No.
Part Name
Amt. Used
Type: 16
Part No.
Type: 18
Part No.
79
Set
(right)
1
1210901608
1210901608
(left)
1
1210901500
1210901500
80
Shaft-lever
1
1210904501
1210904501
81
Lever
1
82
Sleeve-lever
1
83
Set screw , M4xP0.7x10L
1
84
Pinion-rack
1
1210904707
1210904707
85
Key-square , 6x6x20L
1
86
Bearing-niddle , NK20/22
1
91311001
91311001
87
Set screw , M6xP1.0x10L
1
88
Collar
1
1210904805
1210904805
89
Pin-spring , 6x36L
1
90
Gear
1
1210904903
1210904903
91
Bearing-ball , 6003
1
91301005
91301005
92
Cover
1
1210905008
1210905008
93
Pinion-handwheel
1210905106
1210905106
94
Key-square , 6x6x25L
1
95
Bearing-ball , 6004V
1
91301008
91301008
95-1
Bearing-ball , 6005Z
1
91301007
91301007
96
Seat
1210905204
1210905204
97
Hexagon socket screw ,
M6xP1.0x30L
4
99
Washer
1210701608
1210701608
100
Washer-wave type
1
101
Dial-rack
1
1220900202
1220900202
102
Handwheel
1
112210171
112210171
103
Handle
1
1121102002
1121102002
104
Washer-lock
1
1122101901
1122101901
105
Hexagon socket screw ,
8xP1.25x20L
1
106
Dial-thread chasing
(in, 4 parts)
1
1003514708
1003514708
(mm, 5 parts)
1
1003502404
1003502404
(mm, 7 parts)
1
1003514904
1003514904
107
Pin
1
108
Seat-dial shaft
1
1003514502
1003514502
109
Hexagon socket screw ,
10xP1.5x65L
1
110
Gear
(in 16T)
1
1003514600
1003514600
(mm 11T)
1
1003502502
1003502502
(mm 13T)
1
1003502600
1003502600
(mm 14T)
1
1003514806
1003514806
(mm 15T)
1
1003502708
1003502708
(mm 18T)
1
1003502806
1003502806
111
Washer-spring , 10
1
112
Nut , M10xP1.5
1
113
Snap ring , S30
1
