Sharp 16 Series User Manual

29
CARRIAGE AND CROSSFEED ASSEMBLY
Item No.
Part Name
Amt.
Used
Type: 17
Part No.
Type: 19
Part No.
38
Dial-crossfeed (8TPI/export)
1
1000808203
1000808203
(5MM/export)
1
1000802603
1000802603
39
Hexagon socket screw ,
M6xP1.0x15L
1
40
Set screw
1
1120803000
1120803000
41
Handle-wheel (local)
1
1120802601
1120802601
(export)
1
1120802709
1120802709
42
Screw-adjusting , M6xP1.0x30L
1
43
Knob-handle (local)
1
1120803206
1120803206
(export)
1
1120803304
1120803304
43-1
Screw-handle (export)
1
43-2
Knob-handle
1
1120803402
1120803402
44
Plug-oil inlet
1
1122103405
1122103405
45
Lever
1
1120801506
1120801506
46
Screw-carriage clamp
1
1120800607
1120800607
47
Case-wiper
1
48
Wiper
1
1222100102
1222100102
49
Screw-adjusting
1
50
Gib
1
1220800305
1220800305
51
Bolt
1
1120800509
1120800509
52
Cover-cross sliding
1
1430800802
1430800802
53
Shoe-clamp
1
1220800707
1220800707
54
Set screw, M8xP1.25x20L
1
55
Spring
1
56
Button
1
57
Ball-steel , 1/4"
1
58
Hexagon socket screw , M6xP1.0x3
3
59
Screw-gib
2
60
Compound rest
1
61
Gib-compound rest
1
1000804509
1000804509
62
Shoe-clamp
1
1220800707
1220800707
63
Screw-clamp
1
64
Screw-hexa. socket headless cap ,
M8xP1.25x10L
4
65
Shaft-tool post
1
65-1
Shaft-tool post
2
66
Block-tee
1
67
Spring , 1x8x20L
1
68
Sleeve
1
69
Button
1
70
Tool post square
(export)
1
1003512802
1003512606
(local)
1
1003512704
1003512508
71
Screw-square head
1
1000804107
1000804107
72
Bearing-thrust, 51104
1
91303003
91303003
73
Knob-lever
1
1000810605
1000810605
74
Lever
1
1000810605
1000810605
75
Screw-gib, M8xP1.25x31L
1
76
Screw-compound rest
1
1000803904
1000803904
