Sharp 16 Series User Manual

30
CARRIAGE AND CROSSFEED ASSEMBLY
Item No.
Part Name
Amt.
Used
Type: 17
Part No.
Type: 19
Part No.
77
Bearing-thrust, 51102
2
78
Seat-compound rest screw
1
79
Nut
1
80
Collar
1
81
Dial-compound rest
1
1000820003
1000820003
82
Washer-wave type
1
83
Nut
1
84
Handle
1
85
Hexagon socket screw ,
M6xP1.0x16L
1
86
Knob-handle
1
87
Nut, M10xP1.5
4
88
Set screw , M8xP1.25x8L
2
89
Swivel
1
90
Nut-compound rest screw
1
91
Spring washer , M10
4
101
Body-pump
1
1120801800
1120801800
102
Ring-O , P10
1
103
Screw , M5xP0.8x12L
2
104
Rod-pump
1
1120801908
1120801908
105
Stopper
1
1120802003
1120802003
106
Plug
1
1120802101
1120802101
107
Spring-compressing, Ø 1.2x10x63L
1
108
Screw-hexa. Socket head cap,
M6xP1.0x16L
2
