41
AH-S22DP2
AH-S25DP2
AH-S32DP2
REPLACEMENT PARTS LIST [AU-S22DP2/AU-S25DP2/AU-S32DP2]
REF. NO. PART NO. DESCRIPTION Q'TY CODE
CONTROL BOX PARTS
1- 1 CMOTLA902JBEZ Fan motor [AU-S22DP2/S25DP2] 1 BK
1- 1 CMOTLA903JBEZ Fan motor [AU-S32DP2] 1 BL
1- 2 RTRN-A256JBE0 Current transfoemer CT1 1 AG
1- 3 QW-VZD863JBZZ Lead wire (Bulkhead - TBE) 1 AF
1- 4 DPWBFA219JBKZ Electric control board [AU-S22DP2/S25DP2] 1 BQ
1- 4 DPWBFA222JBKZ Electric control board [AU-S32DP2] 1 BR
1- 5 QTANZA001JBZZ Terminal board (4P) 1 AQ
1- 6 RIC--A022BDE0 Integrated circuit IC2 [AU-S22DP2/S25DP2] 1 AE
1- 7 VSKRC245M//-3 Transistor Q3 1 AC
1- 8 VHRPC817X7/1B Photo coupler PC1 1 AE
1- 9 VHRPC853H//-6 Photo coupler PC2 1 AG
1-10 RC-AZA046JBE0 Capacitor [AU-S22DP2/S25DP2] 1 BE
1-10 RC-AZA071JBE0 Capacitor [AU-S32DP2] 1 BD
1-11 RH-DZA117JBE0 Diode bridge [AU-S22DP2/S25DP2] 2 AM
1-11 VHDD25VB60+-1 Diode bridge [AU-S32DP2] 2 AQ
1-12 RH-QXA004JBZZ PTC thermistor 1 AN
1-13 RH-TZA146JBE0 Power transistor module(IPM)[AU-S22DP2/S25DP2] 1 BS
1-13 RH-TZA152JBZZ Power transistor module(IPM)[AU-S32DP2] 1 BY
1-14 PDAI-A126JBWZ Terminal plate 1 AE
1-15 PSEL-C122JBEZ Insulator 1 AC
1-16 RTHM-A022JBE0 Compressor thermistor 1 AN
1-17 RH-IHA010JBZZ Thermistor 1 AX
1-18 RTRN-A195JBE0 Reactor [AU-S22DP2/S25DP2] 1 BA
1-18 RTRN-A230JBE0 Reactor [AU-S32DP2] 1 BB
1-19 DBOX-A030JBYZ Control box assembly 1 AT
1-20 LBND-A042JBE0 Wire fixing band 4 AC
1-21 PSPA-A151JBZZ Spacer 5 AE
1-22 LHLD-A479JBFZ Heat sink holder 1 AE
1-23 PRDAFA152JBEZ Heat sink for powertransistor module 2 AX
1-24 PSEL-C123JBEZ Insulator 1 AC
1-25 PSHE-A190JBEZ Protect sheet 1 AL
1-26 PSEL-C061JBEZ Insulator 1 AE
1-27 PSPA-A144JBE0 Spacer 2 AC
1-28 RFIL-A064JBE0 Ferrite core 4 AF
1-29 QW-VZD858JBZZ Lead wire (T6 - PTC1) 1 AE
1-30 QW-VZE011JBZZ Lead wire (L1 - T6) 1 AF
1-31 QW-VZD857JBZZ Lead wire (Earth) 1 AC
1-32 QW-VZD868JBZZ Lead wire (MRY1 - DB1~) 1 AG
1-33 QW-VZD861JBZZ Lead wire (MRY1 - PTC) 1 AF
1-34 QW-VZD949JBZZ Lead wire (DB1--C8-) 1 AE
1-35 QW-VZD866JBZZ Lead wire (T3 - TB2) 1 AF
1-36 QW-VZD873JBZZ Lead wire (T10 - IPM(-)) 1 AF
1-37 QW-VZD867JBZZ Lead wire (T5 - DB1)) 1 AG
1-38 QW-VZD864JBZZ Lead wire (T2 - TBN) 1 AF
1-39 QW-VZD865JBZZ Lead wire (T1 - TB1) 1 AF
1-40 QW-VZD859JBZZ Lead wire (C8(+) - T7) 1 AE
1-41 QW-VZD950JBZZ Lead wire (DB1+-C8-) 1 AG
1-42 QW-VZD951JBZZ Lead wire (DB2~-C6) 1 AH
1-43 QW-VZD953JBZZ Lead wire (DB2+-L1) 1 AG
1-44 QW-VZD860JBZZ Lead wire (C8(-) - T8) 1 AE
1-45 QW-VZD872JBZZ Lead wire (T9 - IPM(+)) 1 AE
1-46 QW-IZA017JBZZ Lead wire (Compressor wire) [AU-S22DP2/S25DP2] 1 AP
1-46 QW-IZA019JBZZ Lead wire (Compressor wire) [AU-S32DP2] 1 AP
1-47 PSEL-C124JBEZ Insulator 1 AC
1-48 RH-IXA726JBZZ Microcomputer IC1 1 AW
1-49 RH-IZA140JBE0 Integrated circuit IC3 1 AE
1-50 RH-TZA098JBE0 Transistor Q1 1 AB
1-51 RH-VZA020JBE0 Varistor CNR1 1 AB
1-52 RH-VXA002JBZZ Varistor NR1, NR2 2 AD
1-53 QSPGCA003JBZZ Surge absorber SA1 1 AH
1-54 LBNDKA099JBWZ Capacitor clamp 1 AS
1-55 LBNDKA062JBWZ Capacitor clamp 1 AD
1-56 RC-HZA375JBE0 Capacitor [AU-S22DP2/S25DP2] 1 BA
1-56 RC-HZA426JBZZ Capacitor [AU-S32DP2] 1 BE
CABINET AND UNIT PARTS
2- 1 LANGKA124JBPZ Fan motor angle 1 AR
2- 2 LANGKA128JBPZ Fan motor angle sub [AU-S22DP2/S25DP2] 1 AG
2- 2 LANGKA127JBPZ Fan motor angle sub [AU-S32DP2] 1 AE
2- 3 GCAB-A196JBTA Rear cabinet [AU-S22DP2/S25DP2] 1 BD
2- 3 GCAB-A203JBTA Rear cabinet [AU-S32DP2] 1 BC
2- 4 LHLD-A573JBFA Cord clamp 1 AC
To Next Page
