42
AH-S22DP2
AH-S25DP2
AH-S32DP2
2- 5 PFPFPB911JBEZ Motor angle cushion 1 AC
2- 6 GCAB-A195JBTA Front panel 1 BC
2- 7 GGADFA037JBFA Fan guard 1 AT
2- 8 PSEL-C045JBEZ Motor angle cushion 1 AB
2- 9 PSEL-C048JBEZ F panel insulator 1 AC
2-10 PSEL-C049JBEZ F panel insulator 1 AC
2-11 PSEL-C050JBEZ Bulkhead insulator 1 AG
2-12 TLABBA148JBRA Sharp badge 1 AH
2-13 CCHS-A735JBTA Base pan assembly [AU-S32DP2] 1 BD
2-13 CCHS-A739JBTA Base pan assembly [AU-S22DP2/S25DP2] 1 BD
2-14 PFTA-A092JBFA Side cover 1 AQ
2-15 PCOV-A616JBPZ Protect cover 1 AE
2-16 MSPR-A027JBE0 Thermistor spring [AU-S22DP2] 1 AB
2-16 MSPR-A026JBE0 Thermistor spring [AU-S22DP2] 1 AB
2-17 MSPR-A046JBE0 Protector spring [AU-S32DP2] 1 AC
2-17 MSPR-A066JBE0 Protector spring [AU-S22DP2/S25DP2] 1 AD
2-18 NFANPA094JBEZ Propeller fan 1 AX
2-19 DSKR-A102JBYZ Bulkhead spot ass'y [AU-S22DP2/S25DP2] 1 AR
2-19 DSKR-A101JBYZ Bulkhead spot ass'y [AU-S32DP2] 1 AS
2-20 TLABKD294JBEZ Number card [AU-S22DP2] 1 AC
2-20 TLABKD295JBEZ Number card [AU-S25DP2] 1 AC
2-20 TLABKD296JBEZ Number card [AU-S32DP2] 1 AC
2-21 TSPC-E390JBRZ Name badge [AU-S22DP2] 1 AE
2-21 TSPC-E391JBRZ Name badge [AU-S25DP2] 1 AE
2-21 TSPC-E392JBRZ Name badge [AU-S32DP2] 1 AE
2-22 PSEL-C051JBEZ Side cover seal 1 AE
2-23 FFTA-A014JBKZ Side cover assembly 1 AT
2-24 TLABCB728JBRZ Wiring diagram [AU-S22DP2/S25DP2] 1 AE
2-24 TLABCB731JBRZ Wiring diagram [AU-S32DP2] 1 AE
2-25 DCAB-A141JBKZ Top cover assembly 1 AZ
2-26 PSEL-C060JBEZ Insulator for rear cabinet 1 AB
2-27 GCAB-A197JBTA Top cover 1 AX
2-28 PCOV-A617JBFA Reactor cover 1 AE
2-29 PSEL-C046JBEZ Bulkhead insulator [AU-S22DP2/S25DP2] 1 AC
2-29 PSEL-C091JBEZ Bulkhead insulator [AU-S32DP2] 1 AE
2-30 PSEL-C119JBEZ Box insulator 1 AE
2-31 PSEL-C047JBEZ Box insulator 1 AF
2-32 PSEL-C062JBEZ Box insulator 1 AG
2-33 CHLD-A093JBK0 Holder assembly 1 AL
2-34 PSEL-C121JBEZ Side cover seal 1 AC
2-35 PSEL-C120JBEZ Side cover seal 1 AC
2-36 JHNDPA011JBFA Holder 1 AS
2-37 LPLTPA026JBFA Cord clamp plate 1 AC
CYCLE PARTS
3- 1 PSPF-A797JBEZ Compressor cover 1 AM
3- 2 DCPY-A219JBKZ Capillary tube assembly [AU-S22DP2/S25DP2] 1 BE
3- 2 DCPY-A237JBKZ Capillary tube assembly [AU-S32DP2] 1 AS
3- 3 PCON-A451JBPZ Condensor [AU-S22DP2/S25DP2] 1 BS
3- 3 PCON-A449JBPZ Condensor [AU-S32DP2] 1 BT
3- 4 DVLV-A461JBKZ 3 way valve unit [ AU-S22DP2/S25DP2] 1 AY
3- 4 DVLV-A466JBKZ 3 way valve unit [AU-S32DP2] 1 BA
3- 5 LX-NZA147JBE0 Service nut [AU-S22DP2/S25DP2] 1 AK
3- 5 LX-NZA034JBE0 Service nut [AU-S32DP2] 1 AD
3- 6 LX-NZA146JBE0 Bonnet [AU-S22DP2/S25DP2] 2 AF
3- 6 LX-NZA037JBE0 Bonnet [AU-S32DP2] 2 AG
3- 7 DVLV-A462JBKZ 2 way valve unit 1 AW
3- 8 FCMPRA065JBK0
Compressor ass'y(Including for Ref.No.3-9,3-10,3-11)[AU-S32DP2] 1CM
3- 8 FCMPRA103JBKZ
Compressor ass'y(Including for Ref.No.3-9,3-11~3-14,2-17)[AU-S22DP2/S25DP2] 1CD
3- 9 PCMPRA331JBEZ Compressor [AU-S22DP2/S25DP2] 1 CC
3- 9 PCMPRA267JBE0 Compressor [AU-S32DP2] 1 CK
3-10 LBSHCA005JBE0 Terminal bushing [AU-S32DP2] 1 AA
3-11 PCOV-0562JBE0 Terminal cover [AU-S32DP2] 1 AD
3-11 PCOV-A010JBE0 Terminal cover [AU-S22DP2/S25DP2] 1 AF
3-12 PSEL-A403JBE0 Terminal gasket [AU-S22DP2/S25DP2] 1 AB
3-13 PSEL-A150JBE0 Gasket washer [AU-S22DP2/S25DP2] 1 AA
3-14 LX-NZA002JBE0 Special nut [AU-S22DP2/S25DP2] 1 AA
3-15 GLEG-A001JBE0 Compressor cushion [AU-S22DP2/S25DP2] 3 AC
3-15 GLEG-A029JBE0 Compressor cushion [AU-S32DP2] 3 AE
3-16 PSPF-A780JBEZ Compressor cover 1 AT
3-17 PSPF-A779JBEZ Compressor cover 1 AG
3-18 PSEN-A004JBK0 Flare nut ass'y 1 AE
3-19 PSEN-A005JBK0 Flare nut ass'y [AU-S22DP2/S25DP2] 1 AG
3-19 PSEN-A016JBK0 Flare nut ass'y [AU-S32DP2] 1 AR
3-20 PGUM-A135JBEZ Compressor sheet 1 AG
3-21 PMUF-A026JBE0 Muffler [AU-S22DP2/S25DP2] 1 AL
3-21 PMUF-A054JBEZ Muffler [AU-S32DP2] 1 AT
REF. NO. PART NO. DESCRIPTION Q'TY CODE
