43
AH-S22DP2
AH-S25DP2
AH-S32DP2
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
REF. NO. PART NO. DESCRIPTION Q'TY CODE
SCREWS AND NUTS
4- 1 LX-BZA140JBE0 Special screw 35 AB
4- 2 LX-BZA072JBE0 Special screw (for 2/3 way valve unit) 4 AB
4- 3 XTTSA40P14000 Tapping screw 1 AA
4- 4 LX-BZA166JBE0 Special screw 3 AB
4- 5 LX-NZA026JBE0 Special nut (for compressor) 3 AC
4- 6 LX-BZA075JBE0 Special screw 2 AA
4- 7 LX-BZA140JBE0 Special screw 7 AB
4- 8 LX-BZA075JBE0 Special screw (for Earth) 1 AA
4- 9 XBPSD40P20JS0 Machine screw (for IPM) 2 AB
4-10 LX-NZA135JBE0 Special nut (for propeller fan) 1 AC
4-11 XBPSD40P20J00 Machine screw (for DB1, DB2) 2 AA
4-12 XCTSD40P12000
Tapping screw (for Terminal board ass'y angle, for capacitor clamp)
2AA
4-13 XTPSD30P12XS0 Tapping screw 3mm x 16mm (for PWB assembly) 2 AC
4-14 LX-BZA292JBEZ Tapping screw (for Top cover) 8 AA
4-15 XTTSD40P16000 Tapping screw (for Heatsink) 1 AA
4-16 LX-BZA140JBE0 Special screw (for Heatsink holder) 5 AB
4-17 XCTSD40P16000 Tapping screw (for Terminal board ass'y) 1 AA
4-18 XTTSD40P08000 Special screw (for Capacitor clamp) 1 AA
PACKING PARTS
6- 1 CPADBA031JBKZ Bottom pad assembly 1 AS
6- 2 SPAKCB314JBEZ Packing case [AU-S22DP2] 1 AV
6- 2 SPAKCB315JBEZ Packing case [AU-S25DP2] 1 AV
6- 2 SPAKCB316JBEZ Packing case [AU-S32DP2] 1 AV
6- 3 CPADBA032JBKZ Packing pad ass'y 1 AL
To Next Page
