DEFINITION
The definition of each Rank is as follows and also noted in the list
Rank A : Maintenance parts, and consumable parts which are not included in but closely related to maintenance parts
Rank B : Performance/function parts (sensors, clutches, and other electrical parts), consumable parts
Rank E : Unit parts including PWB
Rank D : Preparation parts (External fitting, packing, parts packed together)
Rank C : Parts other than the above (excluding sub components of PWB)
Because parts marked with "!" is indispensable for the machine safety maintenance and operation, it must be replaced with
the parts specific to the product specification.
F Other than this Parts Guide, please refer to documents Service Manual(including Circuit Diagram)of this model.
F Please use the 13 digit code described in the right hand corner of front cover of the document, when you place an order.
F For U.S. only-Use order codes provided in advertising literature. Do not order from parts department.
* These parts are supplied by SMF.
1
Exteriors
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1 CCAB-0003QS22 AS D Front cover
2 LSOU-0001QSJZ AY D Delivery tray
3 XEBS730P08000 AC C Screw(3×8)
4 LSOU-0008QSJZ AH D Extension tray
5 XEBS740P12000 AA N C Screw(4×12)
6 PTPE-0041QSZZ AB C Glass fixing tape B
7 DHAI-0285QSZZ AK C OP-MCU harness
8 PSHEZ0369QSZZ AE C Shading sheet
9 XBBS730P08000 AA N C Screw(3×8)
10 GCAB-0061QSZ1 AK D Left cabinet
11 TLABH0387TSZZ
∗
N
D
Operation instruction label
12
GCOV-0045QSZ7 AK N D Rear cover OC (AL-1552)
GCOV-0045QSZ6 AK N D Rear cover SPF (AL-1553)
13 CFIX-0021QS11 AH D Glass fixing plate
14 PGLSP0007QSZZ AV B Table glass
15 PTPE-0059QSZZ AC C Glass fixing tape A
16 PCOVP0040QSJZ AL D Rear cabinet cover SPF (AL-1553)
17
GCAB-0062QSZ3 AL D Right cabinet OC (AL-1552)
GCAB-0062QSZ2 AN D Right cabinet (AL-1553)
18
GCAB-0004QSJ1 AX D Rear cabinet (AL-1552)
GCAB-0026QSJ2 AZ D Rear cabinet SPF (AL-1553)
20 PMLT-0024QSZZ AC C Fan cushion
21 PFILZ0002QSZZ AL B Ozone filter
22 PTPE-0044QSZZ AC C Slit glass tape (AL-1553)
23 PGLSP0008QSZZ AH B SPF glass (AL-1553)
24 PSHEZ0181QSJZ AC C Rear cabinet sheet (AL-1553)
25 PTPE-0010QSZZ AC C Slit glass tape (AL-1553)
26 TLABZ0531TSZZ
∗
N
D
Class 1 & cautions label
27 PMLT-0069QSZZ AA C Ground cushion (AL-1553)
28 PSHEZ0404QSZZ AF C Right cabinet ground sheet (AL-1553)
29 PTPE-0047QSZZ AC C Ground tape F (AL-1553)
30 PTPE-0048QSZZ AA C Ground tape R (AL-1553)
31 PTPE-0049QSZZ AC C Right cabinet ground tape (AL-1553)
32 PTPE-0060QSZZ AC C Glass aluminum tape
33 PGSK-0034QSZZ AE C Gasket
