AL-1552/AL-1553 DUPLEX-RELATED ITEMS
1 – 5
5. List of simulations
Sim
No.
Kind of
main code
Sub
code
Operation
01 Optical system 01
06
Mirror scan operation
Aging of mirror scanning
02 SPF Individual
load operation
02
03
04
SPF sensor status display
Motor ON
Paper feed solenoid ON
05 Lamp ON check 01
02
03
Operation panel display check
Fusing lamp, cooling fan operation check
Copy lamp ON
06 Machine
individual load
operation
01
02
Paper feed solenoid ON
Resist solenoid ON
07 Aging 01
06
Warm-up display and aging with jam
Intermittent aging
08 High voltage
output check
01
02
03
06
Developing bias
Main charger (Grid high)
Grid voltage (Low)
Transfer charger
10 Other None Toner motor aging
14 Trouble reset None Cancel of troubles other than U2
16 U2 trouble reset None Cancel of U2 trouble
22 Counter display 04
05
08
12
14
17
18
19
21
22
JAM total counter display
Total counter display
SPF counter display
Drum counter display
P-ROM version display
Copy counter display
Printer counter display
Scanner mode counter display
Scanner counter display
SPF JAM counter display
24 Special counter
clear
01
04
07
08
09
13
14
15
JAM total counter clear
SPF counter clear
Drum counter clear
Copy counter clear
Printer counter clear
Scanner counter clear
SPF JAM total counter clear
Scanner mode counter clear
25 Main motor ON 01
10
Main motor operation check (Cooling
fan motor rotation check)
Polygon motor ON
26 Various setup 01
02
03
04
06
07
20
30
38
39
40
42
43
44
62
63
Manual feed setup
(R) SPF setup
Second cassette setup
Machine duplex setup
Destination setup
Machine conditions check
Rear edge void setup
CE mark support control ON/OFF
Cancel of stop at drum life over
Memory capacity check
Polygon motor OFF time setup
Time required for turning OFF after
completion of printing)
Transfer ON timing control setup
Side void setup
SPF document rear edge read setup
Energy-save mode copy lamp setup
Fan control select setup
30 Sensor
operation check
(Standard
provision)
01 Paper sensor status display
43 Fusing
temperature
setup
01
04
05
09
Fusing temperature setup (Normal copy)
Fusing temperature setup 2
Fusing temperature setup in duplex
copy
Setup of fusing control of postcard size
paper
46 Exposure
adjustment
01
02
18
19
20
29
31
32
Copy density adjustment (300dpi)
Copy density adjustment (600dpi)
Image contrast adjustment (300dpi)
γ table setup or AE operation mode setup
SPF exposure correction
Image contrast adjustment (600dpi)
Image sharpness adjustment
Copier color reproduction setup
48 Magnification
ratio correction
01 Front/rear (main scanning) direction and
scan (sub scanning) direction
magnification ratio adjustment
49 01 Flash ROM program writing mode
50 Lead edge
adjustment
01
10
18
19
Lead edge image position
Center offset adjustment
Memory reverse position adjustment
in duplex copy
Duplex copy rear edge void adjustment
51 Timing
adjustment
02 Resist quantity adjustment
53 08 SPF scan position automatic adjustment
61 Laser system
operation
03 Polygon motor check
(HSYNC output check)
63 Shading 01 Shading check
64 Self print 01 Self print
Sim
No.
Kind of
main code
Sub
code
Operation
