6
G
B
ENGLISH
Laser information
SPECIFICATIONS
SOFTWARE LICENSE
The SOFTWARE LICENSE will appear when you install the software from the CD-ROM.
By using all or any portion of the software on the CD-ROM or in the machine, you are
agreeing to be bound by the terms of the SOFTWARE LICENSE.
Wave length 780 nm +15 nm
-10 nm
Pulse times 12.88 µs ±12.88 ns/7 mm
Output power Max 0.2 mW
At the production line, the output power of the scanner unit is adjusted to 0.18
MILLIWATT (Total Power) PLUS 5% and is maintained constant by the operation
of the Automatic Power Control (APC).
Caution
Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
This Digital Equipment is CLASS 1 LASER PRODUCT (IEC 60825-1 Edition 1.2-2001)
AL-2020 AL-2040
Type Digital multifunctional system, desk-top type
Power supply
Local voltage
±
10% (For this copier’s power supply requirement,
see the name plate located on the back of the unit.)
Power consumption Max. 1.0kW
Operating conditions
Temperature: 10°C to 30°C
Humidity: 20% to 85%
Noise level
Sound power level
LwA
Copying mode: 6.4B
Standby mode: 3.3B
Sound pressure level
LpA (reference) (Bystander positions)
Copying mode: 48dB(A)
Standby mode: 17dB(A)
Sound pressure level
LpA (reference) (Operator position)
Copying mode: 52dB(A)
Standby mode: 17dB(A)
Noise emission measurement in accordance with ISO7779.
