Control of the TV
Using a PC
NOTE
• To use this function, select settings of "IP Control".
• The connection will be cut off when there has been no
communication for 3 minutes.
Communication Conditions for IP
Connect to the TV with the following settings made for IP on the PC.
IP protocol:
TCP/IP
Host IP address:
Set the IP address on the TV menu
Service:
None (Do not select Telnet or SSH)
TCP port#:
Set a port number on the TV menu (Control port)
When you set your ID and password on the TV menu, you need to
enter them as soon as you connect to the TV.
Communication Conditions for RS-232C
Set the RS-232C communication settings on the PC to match the
Monitors communication conditions.
The Monitor's communication settings are as follows:
Baud rate:
9,600 /
115,200 baud
Data length:
8 bits
Parity bit:
None
Stop bit:
1 bit
Communication procedure.
Send the control commands from the PC via the RS-232C or IP.
The TV operates according to the received command and sends a
response message to the PC.
Do not send multiple commands at the same time.
Wait until the PC receives the OK response before sending the next
command.

Sharp AQUOS 4P-B65EJ2U Specifications

General

Screen shape	Flat
LED backlight	Yes
Response time	6 ms
Display diagonal	65 \
Display brightness	330 cd/m²
Display technology	LCD
Native aspect ratio	16:9
LED backlighting type	Direct-lit LED
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
Display number of colors	1.07 billion colors
Viewing angle, horizontal	176 °
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1920 x 1080 (HD 1080), 3860 x 2160
Display refresh rates supported	60 Hz
Motion interpolation technology	-
RMS rated power	16 W
Number of speakers	2
Headphone outputs	0
HDMI ports quantity	3
Common interface (CI)	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Power consumption (standby)	- W
Power consumption (typical)	180 W
Package type	Box
Package depth	151.89 mm
Package width	1588.01 mm
Package height	938.02 mm
Package weight	23000 g
Operating temperature (T-T)	0 - 40 °C
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
Control type	Wireless
Stand type	Legs stand
Stand color	Black
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)

Weight and Dimensions

Depth (with stand)	73.66 mm
Width (with stand)	1446 mm
Height (with stand)	835.66 mm
Weight (without stand)	16400 g
