Item 4P-B50EJ2U 4P-B55EJ2U 4P-B65EJ2U 4P-B75EJ2U
LCD Panel
50" Class
(49 33/64" Diagonal)
55" Class
(54 33/64" Diagonal)
65" Class
(64 17/32" Diagonal)
75" Class
(75" Diagonal)
Resolution
8,294,400 pixels (3840 x 2160)
Video color system
NTSC-M/PAL-N/PAL-M
TV
Function
TV
- Standard (CCIR)
American TV Standard ATSC/NTSC System
Receiving
Channel
VHF/UHF
VHF 2-13ch, UHF 14-69ch
CATV
1-135ch (non-scrambled channel only)
Digital Terrestrial
Broadcast (8VSB)
2-69ch
Digital cable*1 (64/256
QAM)
1-135ch (non-scrambled channel only)
STEREO/BILINGUAL
BTSC system
Audio amplifier
8 W x 2
Terminals
Antenna terminal
ANTENNA/CABLE IN (Antenna
input)
75Ω Unbalance, F Type x 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
SERVICE ONLY Ø3.5 mm jack
Ø3.5 mm jack
INPUT 1 (ARC) HDMI
HDMI (HDMI input), ARC
INPUT 2 HDMI
HDMI (HDMI input)
INPUT 3 HDMI
HDMI (HDMI input)
AV IN (INPUT 3)
AUDIO in, VIDEO in
AUDIO OUT
AUDIO out, Headphone (Ø3.5 mm stereo)
USB 1
Photo/Music/Video mode, Software update
USB 2
Photo/Music/Video mode, Software update
EX
-IR External IR receiver connector
ETHERNET (10/100 BASE
-T)
Network connector
OSD language
English/French/Spanish
Power Requirement
AC 120 V, 60 Hz
Power Consumption
130W 130W 180W 300W
Dimensions with stands
1112 x 243 x 672 mm 1228 x 243 x 742 mm 1446 x 285 x 870 mm 1674 x 331 x 1024 mm
Dimensions without stands
1112 x 70 x 642 mm 1228 x 73 x 711 mm 1446 x 73 x 835 mm 1674 x 75 x 960 mm
Weight/Weight without stands
10.0 kg/9.8 kg 13.0 kg/12.8 kg 16.8 kg/16.4 kg 28.9 kg/28.2 kg
Operating temperature
0°C to +40°C
*1 Emergency alert messages via Cable are unreceivable.
• As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification
figures indicated are nominal values of production units. There may be some deviations from these values in individual units.
• Continuous operating time and warranty. This product is designed for a maximum daily use of 16 hours. Continual use in excess of 16 hours per day is not covered by the warranty.
NOTE
• Installing the Liquid Crystal Television requires special skill that should only be performed by qualified service personnel. Customers should not attempt to do the work themselves. SHARP
bears no responsibility for improper mounting or mounting that results in accident or injury.
• Carefully read the instructions that come with the bracket before beginning work.
en-US 59
TV (4P-B50EJ2U/4P-B55EJ2U/4P-B65EJ2U/4P-B75EJ2U)
Specifications

Sharp AQUOS 4P-B65EJ2U Specifications

General

Screen shape	Flat
LED backlight	Yes
Response time	6 ms
Display diagonal	65 \
Display brightness	330 cd/m²
Display technology	LCD
Native aspect ratio	16:9
LED backlighting type	Direct-lit LED
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
Display number of colors	1.07 billion colors
Viewing angle, horizontal	176 °
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1920 x 1080 (HD 1080), 3860 x 2160
Display refresh rates supported	60 Hz
Motion interpolation technology	-
RMS rated power	16 W
Number of speakers	2
Headphone outputs	0
HDMI ports quantity	3
Common interface (CI)	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Power consumption (standby)	- W
Power consumption (typical)	180 W
Package type	Box
Package depth	151.89 mm
Package width	1588.01 mm
Package height	938.02 mm
Package weight	23000 g
Operating temperature (T-T)	0 - 40 °C
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
Control type	Wireless
Stand type	Legs stand
Stand color	Black
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)

Weight and Dimensions

Depth (with stand)	73.66 mm
Width (with stand)	1446 mm
Height (with stand)	835.66 mm
Weight (without stand)	16400 g
