7
Preparation
TV (Rear)
Regarding the headphone jack
• Use headphones with a stereo mini plug (Ø 3.5 mm).
• Be sure to unplug headphones from the jack when they are not
in use.
• The speakers do not output volume when headphones are
plugged in.
• The “Audio” menu cannot be operated when headphones are
plugged in.
• You can set the volume to different levels for each input source.
Volume display when headphones are plugged in
20
RS-232C terminal
INPUT 4 (HDMI) terminal
INPUT 1 terminals
Antenna input terminal
INPUT 2 terminals
AC INPUT terminal
Headphone jack
INPUT 5 (PC Input) terminals
MONITOR OUTPUT
terminals
INPUT 3 (HDMI) terminals
