AR-1118 NOTE FOR THIS SERVICE MANUAL 1-1
[1] NOTE FOR THIS SERVICE MANUAL
This Service Manual describes only the items related to the AR-1118. For the other items common with the AR-M160/M205, please refer to the AR-
M160/205 Service Manual (Document code:00ZARM205/A1E). The table below shows which document(s) should be referred to for each section.
(Refer to the document marked with O.)
[2] SPECIFICATIONS
The table below shows the specifications of this model and the contents of changes from the AR-M160/M205 and AR-1118.
Option
O : The option can be installed.
- : The option cannot be installed.
[3] CONSUMABLE PARTS
1. Supply system table
A. Middle East
Note 1: The individual carton is printed with English, German, French, and Spanish as well as the green mark.
Section AR-M160/M205 AR-1118 Changed item
[ 1 ] GENERAL O
[ 2 ] SPECIFICATIONS O O Some specifications
[ 3 ] CONSUMABLE PARTS O
[ 4 ] EXTERNAL VIEWS AND INTERNAL STRUCTURES O O Appearance / Internal / Operation panel
[ 5 ] UNPACKING AND INSTALLATION O O Changing the copy paper size in the tray
[ 6 ] ADJUSTMENTS O
[ 7 ] SIMULATIONS O O Shifter sensors status display, etc. deleted.
[ 8 ] USER PROGRAMS O O USB2.0 mode switch, etc. deleted.
[ 9 ] TROUBLE CODE LIST O
[10] MAINTENANCE O
[11] DISASSEMBLY AND ASSEMBLY O
[12] FLASH ROM VERSION UP PROCEDURE O
[13] ELECTRICAL SECTION O O Block diagram / Actual wiring diagram 1/7
Item AR-M160 AR-M205 AR-1118
Paper feed system 1cassette +
Multi manual paper feed
2cassette +
Multi manual paper feed
1cassette +
Multi manual paper feed
Copy speed A3 9 11 11
B4 10 12 12
A4 16 20 18
A4R 12 14 14
B5 16 20 18
B5R 14 16 16
A5 - - 18
Weight Approx.31.3Kg Approx.35.1Kg Approx.31.3Kg
Interface USB1.1/USB2.0
IEEE1284
USB1.1/USB2.0
IEEE1284
IEEE1284parallel connector/USB1.1
Machine Model AR-M160 AR-M205 AR-1118 Remark
250 sheets paper feed unit AR-D24 / D25 O O -
SPF AR-SP6N O - O
RSPF AR-RP6 - O -
Original cover AR-VR5 Standard O Standard
NO Name Content Life Product name Remark
1 Toner cartridge(Black)
<With IC>
Toner
(Toner: Net Weight 537g)
Vinyl bag
x10
x10
190K AR-016ET Life setting by A4 6% document
ET=FT*10
2 Developer Developer
(Developer : Net Weight 400g)
x10 500K AR-202CD CD=SD*10
3 Drum kit Drum
Drum fixing plate
x1
x1
50K AR-202DR
