Main Sub
Item Content
Adjustment
code code range
04 07 Checks the
activation of the
upper tray lift-up
motor.
SIMULATION NO. 4- 7
LIFT UP MOTOR ROTATION (UPPER TRAY)
[PAUSE]KEY: END ACTIVATION
[Content] The lift-up operation of the desk upper tray is checked. (The sensor is turned OFF
when the upper limit is detected.)
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
08 Checks the
lift-up operation
of the LCC
cassette.
SIMULATION NO. 4- 8
LIFT UP MOTOR ROTATION (LCC TRAY)
[PAUSE]KEY: END ACTIVATION
[Content] The lift-up operation of the LCC tray is checked. (The sensor is turned OFF when
the upper limit is detected.)
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
10 Checks the
activation of the
transport clutch.
SIMULATION NO. 4-10
TRANSPORT CLUTCH ACTIVATION
[PAUSE]KEY: END ACTIVATION
[Content] The desk transport clutch is turned ON.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
11 Checks the
activation of the
upper tray
paper feed
solenoid.
SIMULATION NO. 4-11
PAPER FEED SOLENOID ACTIVATION
(UPPER TRAY)
[PAUSE]KEY: END ACTIVATION
[Content] The desk’s upper tray paper feed solenoid is turned ON.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
9 – 17
