Main Sub
Item Content
Adjustment
code code range
04 12 Checks the
activation of the
upper tray
paper feed
clutch.
SIMULATION NO. 4-12
PAPER FEED CLUTCH ACTIVATION
(UPPER TRAY)
[PAUSE]KEY: END ACTIVATION
[Content] The desk’s upper tray paper feed clutch is turned ON.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
13 Checks the
activation of the
LCC paper feed
solenoid.
SIMULATION NO. 4-13
PAPER FEED SOLENOID ACTIVATION
(LCC TRAY)
[PAUSE]KEY: END ACTIVATION
[Content] The desk’s LCC paper feed solenoid is turned ON.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
14 Checks the
activation of the
LCC paper feed
clutch.
SIMULATION NO. 4-14
PAPER FEED CLUTCH ACTIVATION
(LCC TRAY)
[PAUSE]KEY: END ACTIVATION
[Content] The desk’s LCC paper feed clutch is turned ON.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
05 Checks the
lighting of lamps.
SIMULATION NO. 5- _
1.DISPLAY LED CHECK
2.HEATER LAMP CHECK
3.COPY LAMP CHECK
4.DISCHARGE LAMP CHECK
6.COPY LAMP POWER SETTING
INPUT SUB NO. AND PRESS PRINT SWITCH
9 – 18
