Main Sub
Item Content
Adjustment
code code range
05 01 Checks the
lighting of LED
lamps on
operation panel.
SIMULATION NO. 5- 1
* SHOW THE DENSITY OF DISPLAY WITH TREE
STAGES.
[PAUSE]KEY: END LAMP CHECK
[Content] All the LED lamps on the operation panel are turned ON and held for 5 seconds.
The RADF lamp (document (document feed/document remaining) comes on, too.
After lighting, the screen returns to the sub code input screen.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
02 Checks lighting
of heater lamp.
SIMULATION NO. 5- 2
HEATER LAMP CHECK
[PAUSE]KEY: END LAMP CHECK
[Content] The heater lamp comes on and goes out 5 time for every 500 ms.
After the operations, the screen returns to the sub code input screen.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
03 Checks lighting
of copy lamp.
• Execution wait mode
SIMULATION NO. 5- 3
COPY LAMP CHECK
COPY LAMP POWER SETTING [XX] :_
(0~55)
INPUT SETUP VALUE AND PRESS PRINT SW
• During execution
SIMULATION NO. 5- 3
COPY LAMP CHECK
COPY LAMP POWER SETTING [XX]
[PAUSE]KEY: END OUTPUT CHECK
9 – 19
