Main Sub
Item Content
Adjustment
code code range
05 03 Checks lighting
of copy lamp.
0-55[Content] When the [PRINT] key is pressed after entering a sub code, the copier enters the
execution wait mode, with the ready lamp coming on and the current copy lamp
voltage setting displayed. The current copy lamp voltage setting can be changed
with the numeric keypad. After that, if the [PRINT] key is pressed, the setting is
stored in memory and the ready lamp goes out. The copy lamp comes on at the
current voltage setting and stays for 6.25 sec. After the operations, the screen
returns to the sub code input screen. (Ready lamp comes on.)
Setting CLPWM duty CL voltage
0: 0% 0 V
11: 20% approx. 30 V
55: 100% approx. 50 V
* The voltage should not be set for the range of 1 to 10, because the CL voltage output may
be unstable.
(a) Operation/display
[PRINT]: If the entered value is valid, the current setting is updated and the copy
lamp comes on. If the entered value is invalid, it is cleared and the error
buzzer sounds. However, the [PRINT] key is pressed without entering any
value, the current setting is not updated and the copy lamp comes on.
[0-9]: Enters lamp voltage settings.
[C]: Clears the entered values.
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
04 Checks lighting
of discharge
lamp.
SIMULATION NO. 5- 4
DISCHARGE LAMP CHECK
[PAUSE]KEY: END LAMP CHECK
[Content] The discharge lamp comes on and stays lit for 30 sec. After the operation, the
screen returns to the sub code input screen.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
06 Sets copy lamp
lighting voltage.
0-55SIMULATION NO. 5- 6
COPY LAMP POWER SETTING [XX] :_
(0~55)
INPUT SETUP VALUE AND PRESS PRINT SW
[Content] the copy lamp lighting voltage can be set. The current setting is displayed and the
operator can set a new value.
Setting CLPWM duty CL voltage
0: 0% 0 V
11: 20% approx. 30 V
55: 100% approx. 50 V
* The voltage should not be set for the range of 1 to 10, because the CL voltage output may
be unstable.
9 – 20
