Main Sub
Item Content
Adjustment
code code range
05 06 Sets copy lamp
lighting voltage.
(a) Operation/display
[PRINT]: If the entered value is valid, the current setting is updated and the screen
returns to the sub code input screen. If the entered value is invalid, the data
in the input field is cleared and the error buzzer sounds. However, the
[PRINT] key is pressed without entering any value, the current setting is not
updated and the screen returns to the sub code input screen.
[0-9]: Enters lamp voltage settings.
[C]: Clears the data in the input field.
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
06 Checks the
activation of
copier
components.
SIMULATION NO. 6- _
MACHINE EACH LOAD ACTIVATION
1.COPIER MAIN SWITCH RESET
2.SEPARATION SOLENOID ACTIVATION
INPUT SUB NO. AND PRESS PRINT SWITCH
01 Copier main
switch reset.
SIMULATION NO. 6-1
COPIER MAIN SWITCH RESET
PRINT SWITCH:EXECUTE SIMULATION
[Content] The copier main switch is reset. After execution of the simulation, the copier power
is turned off.
(a) Operation/display
[START]: The simulation is executed.
[PAUSE] : The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA] : The execution is stopped and the simulation is terminated.
02 Checks drum
separation
solenoid for
activation.
SIMULATION NO. 6- 2
SEPARATION SOLENOID ACTIVATION
[PAUSE]KEY: END ACTIVATION
[Content] The drum separation solenoid is turned ON/OFF by 30 times for every 500 ms.
After the operations, the screen returns to the sub code input screen.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
9 – 21
