Main Sub
Item Content
Adjustment
code code range
22 04 Displays total
JAM counter.
JAM map
display
Cause
PFD PFD paper misfeed (Paper stagnates at PDF or does not reach PPD1.)
PPD1 PPD1 paper misfeed (Paper stagnates at PPD1 or does not reach PPD2.)
PPD2 PPD2 paper misfeed (Paper stagnates at PPD2 or does not reach PSD.)
PSD PSD paper misfeed (Paper stagnates at PSD or does not reach
POD/DPPD1.)
POD POD paper misfeed (Paper stagnates at POD.)
DFPD DFPD paper misfeed (Paper stagnates at DPFD or does not reach PPD1.)
DPPD1 DPPD1 paper misfeed (Paper stagnates at DPPD1 or does not reach
DPPD2.)
DPPD2 DPPD2 paper misfeed (Paper stagnates at DPPD2 or does not reach
DTPD.)
MPF Multiple paper feed section paper misfeed (MPFS is ON and paper does not
reach PPD2.)
LCS Bottom CS paper misfeed (CPFC2 is ON and paper does not reach PFD.)
UCS Top CS paper misfeed (CPFC1 is ON and paper does not reach PPD1.)
ADU ADU paper misfeed (DPFC is ON and paper does not reach DPFD.)
D1CS Desk upper tray paper misfeed (DPFC1 is ON and paper does not reach
DPOD1.)
D2CS Desk LCC tray paper misfeed (DPFC2 is ON and paper does not reach
DPOD2.)
DPOD1 Paper stagnates at DPOD1.
DPOD12 Paper does not reach DPOD2 with DPOD1 turned ON.
DPOD2 Paper stagnates at DPOD2.
DPOD23 Paper does not reach DPOD3 with DPOD2 turned ON.
DPOD3 Paper stagnates at DPOD3.
ST_I1 Paper does not reach sorter inlet sensor (SF-S15)
Paper does not reach non-sort sensor transport section (SF-S53)
ST_I2 Paper stagnates at sorter inlet sensor (SF-S15)
Paper does not reach non-sort sensor transport section (SF-S53)
ST_01 Paper does not reach sorter paper exit sensor (SF-S15)
Paper does not reach sort sensor transport section (SF-S53)
ST_02 Paper does not stagnates sorter paper exit sensor (SF-S15)
Paper stagnates at sort sensor transport section (SF-S53)
ST_ID Non-sort sensor door open paper misfeed (SF-S53)
ST_OD Sort sensor third door open paper misfeed (SF-S53)
DF_PFD RADF spare paper misfeed
DF_SET RADF paper misfeed
DF_EXT RADF paper exit error
DF_REV RADF inversion error
9 – 33
