Main Sub
Item Content
Adjustment
code code range
24 02 Clears trouble
counter.
[Content] The trouble counter is cleared. After that, the trouble counter is displayed.
(a) Operation/display
[1]: The simulation is executed and the screen changes to the trouble counter
screen.
[2]: The simulation is stopped and the screen returns to the sub code input
screen.
If any key other than [1 or [2] is pressed, the error buzzer sounds.
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
03 Clears tray and
ADU counter.
SIMULATION NO.24- 3
TRAY AND ADU COUNTER CLEAR
SELECT NUMBER 1 to 5
1.TRAY 1 (COPIER LOWER)
2.TRAY 2 (DESK UPPER)
3.TRAY 3 (DESK LCC)
4.MANUAL FEED TRAY
5.DUPLEX UNIT
SELECT WITH TEN KEY AND PRESS PRINT SW
• [1-5] keys/[PRINT] key
SIMULATION NO.24- 3
COUNTER CLEAR HAS COMPLETED
* * * COUNTER DISPLAY
* * * : 000,000
[PAUSE]KEY: END DISPLAY
[Content] A selected counter is cleared. After that, the counter value is displayed.
FIRST TRAY Tray 1: Copier lower tray
SECOND TRAY Tray 2: Desk upper tray
THIRD TRAY (LCC) Tray 3 : Desk lower tray (LCC)
MANUAL FEED TRAY : Manual feed tray
DUPLEX UNIT : ADU
(a) Operation/display
[1-5]: If the [PRINT] key is pressed, the simulation is executed and the ADU
counter screen is displayed. Any key other than [1] thru [5] is pressed, the
error buzzer sounds.
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
9 – 40
