Main Sub
Item Content
Adjustment
code code range
44 04 Sets standard
patch density.
0-255SIMULATION NO.44- 4
PROCESS CONTROL INITIAL DENSITY SETUP
INITIAL DENSITY[XXX]: XXX
(0~255)
INPUT SETUP VALUE AND PRESS PRINT SW
[Content] The current setting of the standard patch density during process controlling is
displayed and a new setting can be set.
(a) Operation/display
[PRINT]: If the entered value is valid, the current setting is updated and the sub code
input screen is displayed. If the entered value is not valid, the input field is
cleared and the error buzzer sounds.
If any value is not entered, the setting is not updated and the screen
changes to the sub code input screen.
[0-9]: Enters settings.
[C]: Clears the input field.
[PAUSE]: No setting is made and the sub code input screen is displayed.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
07 Checks gain
selection
between DM/ID
sensors.
SIMULATION NO.44- 7
DM/ID SENSOR GAIN CHECK
DM7:XXX , ID7:XXX
DM6:XXX , ID6:XXX
DM5:XXX , ID5:XXX
DM4:XXX , ID4:XXX
DM3:XXX , ID3:XXX
DM2:XXX , ID2:XXX
DM1:XXX , ID1:XXX
[PAUSE]KEY:END DISPLAY
[Content] The output levels of the drum marking sensor and the image density sensor
obtained when the gain rank is selected can be checked.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
09 Displays
process control
data.
SIMULATION NO.44- 9
PROCESS CONTROL DATA DISPLAY P_CNT:X
DRUM COUNT :XX,XXX,XXX STD_PAT :XXX
GR(ORG/ADJ) DV(ORG/ADJ) LD(ORG/ADJ)
AUTO :XXX/XXX XXX/XXX XXX/XXX
MANUAL:XXX/XXX XXX/XXX XXX/XXX
PHOTO :XXX/XXX XXX/XXX XXX/XXX
SOFT_P:XXX/XXX XXX/XXX XXX/XXX
T/S :XXX/XXX XXX/XXX XXX/XXX
PRINT :XXX/XXX XXX/XXX XXX/XXX
[PAUSE]KEY:END DISPLAY
9 – 63
