Main Sub
Item Content
Adjustment
code code range
44 09 Displays
process control
data.
[Content] Process control data are displayed.
STD_PAT The standard patch density (Setting of SIM44-04)
DRUM_CNT Drum adjustment counter
P_CNT Patch read count in the previous process control
GRID_BIAS (ORG) Grid bias setting
GRID_BIAS (ADJ) Grid bias adjustment value
DV_BAIS (ORG) Developing bias setting
DV_BIAS (ADJ) Developing bias adjustment value
LD_POWER (ORG) Laser power setting
LD_POWER (ADJ) Laser power adjustment value
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
12 Displays DM/ID
patch and drum
base output.
SIMULATION NO.44-12
DM/ID PATCH, DRUM BASE OUTPUT DISPLAY
GAIN PT1/BS1 PT2/BS2 PT3/BS3
DM : X XXX/XXX
ID(1): X XXX/XXX XXX/XXX XXX/XXX
(2): X XXX/XXX XXX/XXX XXX/XXX
(3): X XXX/XXX XXX/XXX XXX/XXX
(4): X XXX/XXX XXX/XXX XXX/XXX
(5): X XXX/XXX XXX/XXX XXX/XXX
[PAUSE]KEY:END DISPLAY
[Content] The outputs of DM/ID patch and drum base in the previous process control are
displayed.
DM GAIN DM sensor gain
PT1 Output of DM sensor marking section
BS1 Output of DM sensor drum base
ID (1) GAIN 1st gain of IS sensor
PT1 1st output of ID sensor patch 1
BS1 1st output of ID sensor drum base
PT2 1st output of ID sensor patch 2
BS2 1st output of ID sensor drum base
PT3 1st output of ID sensor patch 3
BS3 1st output of ID sensor drum base
ID (2) 2nd output of ID sensor
ID (3) 3rd output of ID sensor
ID (4) 4th output of ID sensor
ID (5) 5th output of ID sensor
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
