AR-5316/5320 NOTE FOR THIS SERVICE MANUAL 1-1
[1] NOTE FOR THIS SERVICE MANUAL
This Service Manual describes only the items related to the AR-5316 and AR-5320. For the other items common with the AR-M160/M205, please refer
to the AR-M160/205 Service Manual (Document code:00ZARM205/A1E). The table below shows which document(s) should be referred to for each
section. (Refer to the document marked with O.)
[2] SPECIFICATIONS
The table below shows the specifications of this model and the contents of changes from the AR-M160/M205 and AR-5316/5320.
Option
O : The option can be installed.
- : The option cannot be installed.
Section AR-M160/M205 AR-5316/AR-5320 Changed item
[ 1 ] GENERAL O
[ 2 ] SPECIFICATIONS O O Some specifications
[ 3 ] CONSUMABLE PARTS O
[ 4 ] EXTERNAL VIEWS AND INTERNAL STRUCTURES O O Appearance / Internal / Operation panel
[ 5 ] UNPACKING AND INSTALLATION O O Changing the copy paper size in the tray
[ 6 ] ADJUSTMENTS O
[ 7 ] SIMULATIONS O O Shifter sensors status display, etc. deleted.
[ 8 ] USER PROGRAMS O O USB2.0 mode switch, etc. deleted.
[ 9 ] TROUBLE CODE LIST O
[10] MAINTENANCE O
[11] DISASSEMBLY AND ASSEMBLY O
[12] FLASH ROM VERSION UP PROCEDURE O
[13] ELECTRICAL SECTION O O Block diagram / Actual wiring diagram 1/7
Item AR-M160 AR-5316 AR-M205 AR-5320
Paper feed system 1cassette +
Multi manual paper feed
One automatic feeding paper
tray(250sheets) +
bypass tray(100sheets)
2cassette +
Multi manual paper feed
Two automatic feeding paper
trays(250sheets each) +
bypass tray(100sheets)
Weight Approx.31.3Kg Approx.31.3Kg
(Not including TD cartridge)
Approx.35.1Kg Approx.36.3Kg
(Not including TD cartridge)
Interface USB1.1/USB2.0
IEEE1284
IEEE1284parallel connector/
USB1.1
USB1.1/USB2.0
IEEE1284
IEEE1284parallel connector/
USB1.1
Machine Model AR-M160 AR-M205 AR-5316 AR-5320 Remark
250 sheets paper feed unit AR-D24 / D25 O O - -
SPF AR-SP6 O - O O
RSPF AR-RP6 - O - -
Original cover AR-VR5 Standard O Standard Standard
[01_02]NOTE_SPEC.fm 1 ページ ２００３年１２月１９日 金曜日 午後４時９分
