Chapter 1
1
This chapter provides basic information that you should know before using the machine.
PART NAMES
Document glass Paper output tray extension
Operation panel Power switch
Front cover Handles
Paper tray Power cord socket
Side cover
Fusing unit release lever
Side cover open button Transfer charger
Bypass tray paper guides Charger cleaner
Original output tray extension Paper holder arm
Paper output tray
Photoconductive
drum
RSPF (Option)
Original cover
Exit area
2
3
4
1
5
7
6
9
8
10
11
12
14
15
16
Bypass tray
Original guides
Document feeder tray
Document
feeder cover
5
3
12
Toner cartridge
Interface
USB
connector
13
17
1
10
2
11
3
12
4
13
5
14
6
15
7
16
8
17
9
