AY-X36RU
AE-X36RU
19
6.
IPM Protection, Out-of-step Fault, Compressor Phase Overcurrent (AP1: the control panel of the
outdoor unit)
Main Check Points:
● If the connection between control panel AP1 and compressor COMP is secure? If loose? If the connection is in correct order?
● If the voltage input of the machine is within normal range? (Use AC voltmeter to measure the voltage between terminal L andN
on the wiring board XT)
● If the compressor coil resistance is normal? If the insulation of compressor coil against the copper tube is in good condition?
● If the working load of the machine are too high? If the radiation is good?
● If the charge volume of refrigerant is correct?
Energize and
switch on
IPM protection
occurs after the
machine has run for
a
p
eriod of time?
Please confirm:
1. If the indoor and outdoor heat exchangers are dirty? If they are obstructed by other objects which affect the
heat exchange of indoor and outdoor unit.
2. If the indoor and outdoor fans are working normally?
3. If the environment temperature is too high, resulting in that the system pressure is too high and exceeds the
permissible range?
4. If the charge volume of refrigerant is too much, resulting in that the system pressure is too high?
5. Other conditions resulting in that the system pressure becomes too high.
Take corrective actions
according to Technical
Service Manual, and
then energize and start
the unit.
If there is any
abnormality
described above?
Replace the
control panel AP1
If the connection
between AP1 and
COMP is unsecure
or the connection
order is wrong?
Connect the control panel
A
P1 and compressor
COMP correctly according
to the Electrical Wiring
Diagram. Then, energize
and start the unit.
Use ohmmeter to
measure the resistance
between the three
terminals on compressor
COMP, and compare the
measurements with the
compressor resistance on
Service Manual.
If the
resistance is
normal?
Use ohmmeter to
measure the resistance
between the two
terminals of compressor
COMP and copper tube.
Replace the
compressor
COMP
Resistance higher
than 500MΩ?
Replace the
control panel
AP1
END
If the unit can
work normally?
Y
Y
N
N
If the unit can
work
normally?
Y
Y
Y
N
Y
N
Refer to the
Electrical Wiring
Diagram and check
if the connection
between AP1 and
COMP is loose and if
the connection order
is correct.
N
N
