AY-X36RU
AE-X36RU
31
REFRIGERATION CYCLE
[1] Refrigerant System Diagram
Indoor unit
Outdoor unit
COOLING
HEATING
4-Way valve
Discharge
Suction
Heat
exchanger
(evaporator)
Heat
exchanger
(condenser)
Valve
Valve
Liquid pipe
side
Gas pipe
side
Strainer
Electron
expansion
valve
Strainer
Accumlator
Compressor
Connection pipe specication:
Liquid pipe:1/4 inch (6.35mm)
Gas pipe:5/8 inch (16mm)
[2] PERFORMANCE CURVES
1. Operation Characteristic Curve
Cooling
Heating
0
2
4
6
8
10
12
14
0 20 40 60 80 100 120
0
2
4
6
8
10
12
14
0 20 40 60 80 100 120
Conditio
n
Indoor:DB 80.6°F
WB66.2 °F
Indoor air flow: Super High
Pipe length:24.6ft
Condition
Indoor:DB 70°F
Indoor air flow: Super High
Pipe length:24.6ft
Compressor Frequency(Hz)
Compressor Frequency(Hz)
Current(A) Current(A)
