IT-2
1 Entrata (dell’aria)
2 Pannello aperto
3
Filtro di puri cazione dell’aria
4 Filtri dell’aria
5 Tasto AUX
6 Finestra di ricezione
7 Deflettore di regolazione
verticale del usso d’aria
8
De ettore di regolazione oriz-
zontale del usso d’aria
9 Uscita (d’aria)
10 Spia PLASMACLUSTER
(blu)
11 Spia OPERATION
(rosso
)
12 Spia TIMER
(arancione
)
13 Spia FULL POWER
(MASSIMA POTENZA)
(verde
)
14 Spia SELF CLEAN
(AUTOPULIZIA) (verde
)
NOTE:
Le unità effettive potrebbero dif-
ferire leggermente da quelle illu-
strate sopra.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
NOMI DEI COMPONENTI
UNITA INTERNA
