Sharp AY-XP9RMR - Part Names

GB-2
INDOOR UNIT
1 Inlet (Air)
2 Open Panel
3 Air Filter
4 AUX Button
5 Receiver Window
6 Power Supply Cord
7 Vertical Airow Louver
8 Horizontal Airow Louver
9 Outlet (Air)
10 PLASMACLUSTER Lamp (blue
)
11 TURBO FAN Lamp (red
)
12 TIMER Lamp (orange
)
13 OPERATION Lamp (green
)
14 Inlet (Air)
15 Refrigerant Pipe and Interconnecting
Cord
16 Drainage Hose
17 Outlet (Air)
NOTE:
Actual units might vary slightly from
those shown above.
OUTDOOR UNIT
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
PART NAMES
