Sharp CD-BA3000 User Manual

NO.
PRICE
RANK
DESCRIPTION
PARTS CODENO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-BA3000
R581 VRD-MN2BD683J J AA 68 kohms,1/8W
R582 VRD-MN2BD123J J AA 12 kohms,1/8W
R583 VRD-MN2BD683J J AA 68 kohms,1/8W
R584 VRD-MN2BD123J J AA 12 kohms,1/8W
R585,586 VRD-MN2BD224J J AA 220 kohms,1/8W
R587,588 VRD-MN2BD394J J AA 390 kohms,1/8W
R589,590 VRD-MN2BD104J J AA 100 kohm,1/8W
R605,606 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R607,608 VRD-MN2BD103J J AA 10 kohm,1/8W
R609,610 VRD-ST2CD331J J AA 330 ohms,1/6W
R611,612 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R613,614 VRD-MN2BD331J J AA 330 ohms,1/8W
R615,616 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R617,618 VRD-MN2BD821J J AA 820 ohms,1/8W
R619 VRD-MN2BD223J J AA 22 kohms,1/8W
R620 VRD-ST2CD223J J AA 22 kohms,1/6W
R621,622 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R631,632 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R633,634 VRD-MN2BD393J J AA 39 kohms,1/8W
R637 VRD-MN2BD474J J AA 470 kohms,1/8W
R638 VRD-ST2CD474J J AA 470 kohms,1/6W
R700 VRD-ST2CD103J J AA 10 kohm,1/6W
R701 VRD-ST2CD104J J AA 100 kohm,1/6W
R702 VRD-ST2CD102J J AA 1 kohm,1/6W
R704 VRD-ST2CD104J J AA 100 kohm,1/6W
R705 VRD-ST2CD102J J AA 1 kohm,1/6W
R706~709 VRD-MN2BD103J J AA 10 kohm,1/8W
R710 VRD-MN2BD102J J AA 1 kohm,1/8W
R712 VRD-MN2BD103J J AA 10 kohm,1/8W
R713~715 VRD-MN2BD104J J AA 100 kohm,1/8W
R716 VRD-ST2CD104J J AA 100 kohm,1/6W
R717 VRD-MN2BD102J J AA 1 kohm,1/8W
R719 VRD-ST2CD102J J AA 1 kohm,1/6W
R724 VRD-MN2BD330J J AA 33 ohms,1/8W
R725,726 VRD-ST2CD103J J AA 10 kohm,1/6W
R728 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R732,733 VRD-MN2BD683J J AA 68 kohms,1/8W
R734 VRD-MN2BD102J J AA 1 kohm,1/8W
R735 VRD-MN2BD474J J AA 470 kohms,1/8W
R736,737 VRD-MN2BD103J J AA 10 kohm,1/8W
R738 VRD-MN2BD102J J AA 1 kohm,1/8W
R739 VRD-MN2BD474J J AA 470 kohms,1/8W
R740~743 VRD-MN2BD102J J AA 1 kohm,1/8W
R744 VRD-ST2CD102J J AA 1 kohm,1/6W
R746 VRD-ST2CD103J J AA 10 kohm,1/6W
R747 VRD-ST2CD102J J AA 1 kohm,1/6W
R748 VRD-MN2BD102J J AA 1 kohm,1/8W
R749 VRD-MN2BD103J J AA 10 kohm,1/8W
R750 VRD-MN2BD102J J AA 1 kohm,1/8W
R751,752 VRD-MN2BD103J J AA 10 kohm,1/8W
R753 VRD-ST2CD182J J AA 1.8 kohms,1/6W
R754~756 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R757 VRD-MN2BD103J J AA 10 kohm,1/8W
R758,759 VRD-MN2BD102J J AA 1 kohm,1/8W
R760~762 VRD-ST2CD102J J AA 1 kohm,1/6W
R763~765 VRD-MN2BD103J J AA 10 kohm,1/8W
R766,767 VRD-MN2BD102J J AA 1 kohm,1/8W
R768 VRD-ST2CD102J J AA 1 kohm,1/6W
R769~773 VRD-MN2BD102J J AA 1 kohm,1/8W
R775 VRD-ST2CD102J J AA 1 kohm,1/6W
R776 VRD-MN2BD102J J AA 1 kohm,1/8W
R777 VRD-MN2BD103J J AA 10 kohm,1/8W
R778~780 VRD-MN2BD102J J AA 1 kohm,1/8W
R781~786 VRD-ST2CD102J J AA 1 kohm,1/6W
R787~790 VRD-MN2BD102J J AA 1 kohm,1/8W
R791 VRD-ST2CD103J J AA 10 kohm,1/6W
R794 VRD-MN2BD102J J AA 1 kohm,1/8W
R795 VRD-MN2BD103J J AA 10 kohm,1/8W
R796 VRD-MN2BD473J J AA 47 kohms,1/8W
R797 VRD-MN2BD104J J AA 100 kohm,1/8W
R798 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R799 VRD-MN2BD101J J AA 100 ohm,1/8W
R801 VRD-ST2CD101J J AA 100 ohm,1/6W
R802 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R803 VRD-ST2CD123J J AA 12 kohms,1/6W
R810~812 VRD-ST2CD102J J AA 1 kohm,1/6W
R804 VRD-ST2CD102J J AA 1 kohm,1/6W
R805 VRD-ST2EE100J J AA 10 ohm,1/4W
R809 VRD-ST2CD473J J AA 47 kohms,1/6W
R850 VRD-RT2HD3R3J J AA 3.3 ohms,1/2W
R851 VRD-ST2CD330J J AA 33 ohms,1/6W
R852 VRD-ST2EE223J J AA 22 kohms,1/4W
R853 VRD-ST2CD223J J AA 22 kohms,1/6W
R854 VRD-ST2CD103J J AA 10 kohm,1/6W
R855 VRD-RT2HD3R3J J AA 3.3 ohms,1/2W
R860 VRD-MN2BD223J J AA 22 kohms,1/8W
R861 VRD-MN2BD683J J AA 68 kohms,1/8W
R862,863 VRD-MN2BD333J J AA 33 kohms,1/8W
R864 VRD-MN2BD154J J AA 150 kohms,1/8W
R868,869 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R870 VRD-ST2CD102J J AA 1 kohm,1/6W
R871 VRD-ST2EE103J J AA 10 kohm,1/4W
R872,873 VRD-MN2BD102J J AA 1 kohm,1/8W
R874 VRD-ST2CD104J J AA 100 kohm,1/6W
R875 VRD-MN2BD104J J AA 100 kohm,1/8W
R878,879 VRD-MN2BD223J J AA 22 kohms,1/8W
R880 VRD-ST2CD104J J AA 100 kohm,1/6W
R901,902 VRD-ST2CD102J J AA 1 kohm,1/6W
R903,904 VRD-ST2CD563J J AA 56 kohms,1/6W
R905,906 VRD-ST2CD102J J AA 1 kohm,1/6W
R907,908 VRD-ST2CD391J J AA 390 ohms,1/6W
R909,910 VRD-ST2CD563J J AA 56 kohms,1/6W
R911 VRD-ST2CD333J J AA 33 kohms,1/6W
! R912,913 VRG-ST2EC101J J AB 100 ohm,1/4W,Fusible
R915,916 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R917,918 VRN-VV3LAR10J J 0.1 ohm,3W
R919,920 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R921,922 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R923 VRD-ST2CD563J J AA 56 kohms,1/6W
R925~928 VRD-RT2HD100J J AA 10 ohm,1/2W
R929,930 VRD-ST2CD563J J AA 56 kohms,1/6W
R931,932 VRD-RT2HD4R7J J AA 4.7 ohms,1/2W
R933,934 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R935 VRD-RT2HD4R7J J AA 4.7 ohms,1/2W
R936 VRD-ST2EE221J J AA 220 ohms,1/4W
R937 VRD-ST2CD153J J AA 15 kohms,1/6W
R938 VRD-ST2CD683J J AA 68 kohms,1/6W
R939 VRD-ST2CD102J J AA 1 kohm,1/6W
R941,942 VRS-VV3DA561J J AC 560 ohms,2W
R943 VRS-VV3DA681J J AC 680 ohms,2W
R949 VRD-ST2CD474J J AA 470 kohms,1/6W
R950 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R959 VRD-ST2CD822J J AA 8.2 kohms,1/6W
R960 VRD-ST2CD103J J AA 10 kohm,1/6W
R961,962 VRD-ST2CD473J J AA 47 kohms,1/6W
RD1 VRD-MN2BD681J J AA 680 ohms,1/8W
RD2 VRD-MN2BD821J J AA 820 ohms,1/8W
RD3 VRD-ST2CD102J J AA 1 kohm,1/6W
RD4 VRD-MN2BD152J J AA 1.5 kohms,1/8W
RD5 VRD-MN2BD222J J AA 2.2 kohms,1/8W
RD6 VRD-MN2BD272J J AA 2.7 kohms,1/8W
RD7 VRD-MN2BD392J J AA 3.9 kohms,1/8W
RD8 VRD-MN2BD562J J AA 5.6 kohms,1/8W
RD9 VRD-MN2BD103J J AA 10 kohm,1/8W
RD10 VRD-MN2BD183J J AA 18 kohms,1/8W
RD11 VRD-MN2BD333J J AA 33 kohms,1/8W
RD12 VRD-MN2BD104J J AA 100 kohm,1/8W
RD13 VRD-ST2CD681J J AA 680 ohms,1/6W
RD14 VRD-MN2BD821J J AA 820 ohms,1/8W
RD25 VRD-ST2CD681J J AA 680 ohms,1/6W
RD26 VRD-ST2CD821J J AA 820 ohms,1/6W
RD27 VRD-ST2CD102J J AA 1 kohm,1/6W
RD28 VRD-MN2BD152J J AA 1.5 kohms,1/8W
RD29 VRD-MN2BD222J J AA 2.2 kohms,1/8W
RD30 VRD-MN2BD272J J AA 2.7 kohms,1/8W
RD31 VRD-MN2BD392J J AA 3.9 kohms,1/8W
RD32 VRD-MN2BD562J J AA 5.6 kohms,1/8W
RD33 VRD-MN2BD103J J AA 10 kohm,1/8W
RD34 VRD-ST2CD183J J AA 18 kohms,1/6W
RD35 VRD-ST2CD333J J AA 33 kohms,1/6W
RD36 VRD-MN2BD104J J AA 100 kohm,1/8W
RS710 VRD-MN2BD102J J AA 1 kohm,1/8W
RS712~714 VRD-MN2BD102J J AA 1 kohm,1/8W
RS718 VRD-MN2BD103J J AA 10 kohm,1/8W
RS719 VRD-MN2BD223J J AA 22 kohms,1/8W
RS720~722 VRD-MN2BD102J J AA 1 kohm,1/8W
RS723~725 VRD-ST2CD102J J AA 1 kohm,1/6W
RS727,728 VRD-MN2BD102J J AA 1 kohm,1/8W
RS729,730 VRD-MN2BD681J J AA 680 ohms,1/8W
OTHER CIRCUITRY PARTS
BI1A/B QCNWN1608AWZZ J Connector Ass’y,2/2Pin
– 4 –
