Sharp CD-BA3000 - Page 59

CD-BA3000
– 59 –
A
B
C
D
E
F
G
H
1
23456
Figure 10 SPEAKER EXPLODED VIEW (1/2)
– 10 –
CP-BA3000
Woofer
SP1 (L-ch)
SP2 (R-ch)
Woofer
SP1 (L-ch)
SP2 (R-ch)
Cement
Resistor
Tweeter
SP3 (L-ch)
SP4 (R-ch)
Tweeter
SP3 (L-ch)
SP4 (R-ch)
Super Tweeter
SP5 (L-ch)
SP6 (R-ch)
Super
Tweeter
SP5 (L-ch)
SP6 (R-ch)
902
913x4
905x4
910x4
901
912x4
903
906
907
907
907
909
908
911x4
911x2
Cement
Resistor
Film
Capacitor
SP5,6
SP3,4
SP1,2
904
Polyswitch
Film Capacitor
3.3µF/100V
Polyswitch
Polyswitch
Cement
Resistor
6.8Ω/40W
RD
BK
BK
RD
BK
RD
RD
Speaker
Terminal
Film
Capacitor
