Sharp CD-BA3000 User Manual

CD-BA3000
– 8 –
1 Front Panel 1. Net Frame Ass'y .... (A1) x1 8-3
2. Caching Holder ...... (A2) x4
3. Screw ..................... (A3) x4
2 Tweeter 1. Screw ..................... (B1) x4 8-4
3 Super Tweeter 1. Screw .................... (C1) x2 8-4
4 Woofer 1. Screw .................... (D1) x4 8-4
STEP
REMOVAL PROCEDURE FIGURE
Figure 8-3
Figure 8-1 Figure 8-2
CP-BA3000
Figure 8-4
(P2) x2
(P1) x2
(P2) x2
CD Servo
PWB
CD Player
Chassis
(Q2) x3
(Q1) x1
(R1) x5
(Q1) x1
Loading
Motor
PWB
CD
Mechanism
(A3)x4
ø4x20mm
(A2)x4
(A1)x1
(C1)x2
ø3x10mm
(B1)x4
ø3x10mm
(D1)x4
ø4x12mm
Woofer
Front Panel
Tweeter
Super
Tweeter
