Sharp CD-BK250W Service Manual

PRICE
RANK
DESCRIPTION
NO.
PARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-BK250W/CD-BK2600W/CD-BK270W
CK17 VCEAEA1AW227M J 220 µF,10V,Electrolytic
CK19 VCTYBT1EF223Z J AA 0.022 µF,25V
CK20 VCFYHA1HA224J J AC 0.22 µF,50V,Thin Film
CK21 VCFYDA1HA683J J AB 0.068 µF,50V,Polyester
CK22 VCTYPA1CX472K J AA 0.0047 µF,16V
CK23 VCKYPA1HB102K J AA 0.001 µF,50V
CK24~26 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
CK29,30 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
CK31 VCFYDA1HA154J J AB 0.15 µF,50V,Polyester
CK33~35 VCCSBT1HL470J J AA 47 pF,50V
CK41 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
CK42 VCTYBT1EF223Z J AA 0.022 µF,25V
CK43,44 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
CK45,46 RC-EZY225AF1H J AB 2.2 µF,50V,Electrolytic
CK47,48 VCCSPA1HL221J J AA 220 pF,50V
CK49,50 VCCSPA1HL101J J AA 100 pF,50V
CK51,52 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
CK53 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
CK72 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
CR1,2 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
CT1 VCKZPA1HF103Z J AA 0.01 µF,50V
RESISTORS
VRD-MN2BD000C J AA 0 ohm,Jumper,ø1.4×3.5mm,Ivory
R1,2 VRD-ST2CD123J J AA 12 kohms,1/6W
R3 VRD-ST2CD333J J AA 33 kohms,1/6W
R4,5 VRD-ST2CD123J J AA 12 kohms,1/6W
R6 VRD-ST2CD333J J AA 33 kohms,1/6W
R7 VRD-ST2CD470J J AA 47 ohms,1/6W
R9 VRD-ST2CD3R3J J AA 3.3 ohms,1/6W
R10 VRD-ST2CD273J J AA 27 kohms,1/6W
R11 VRD-MN2BD103J J AA 10 kohm,1/8W
R12 VRD-MN2BD331J J AA 330 ohms,1/8W
R13~17 VRD-MN2BD102J J AA 1 kohm,1/8W
R18 VRD-ST2CD102J J AA 1 kohm,1/6W
R19 VRD-ST2CD153J J AA 15 kohms,1/6W
R20 VRD-ST2CD103J J AA 10 kohm,1/6W
R22 VRD-ST2CD101J J AA 100 ohm,1/6W
R23 VRD-MN2BD221J J AA 220 ohms,1/8W
R24,25 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R26,27 VRD-MN2BD103J J AA 10 kohm,1/8W
R28,29 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R30 VRD-ST2CD822J J AA 8.2 kohms,1/6W
R31~38 VRD-ST2CD102J J AA 1 kohm,1/6W
R39,40 VRD-MN2BD681J J AA 680 ohms,1/8W
R41 VRD-MN2BD123J J AA 12 kohms,1/8W
R42 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R43 VRD-MN2BD101J J AA 100 ohm,1/8W
R44 VRD-ST2CD123J J AA 12 kohms,1/6W
R45,46 VRD-MN2BD471J J AA 470 ohms,1/8W
R47 VRD-MN2BD101J J AA 100 ohm,1/8W
R49 VRD-ST2EE1R0J J AA 1 ohm,1/4W
R65 VRD-ST2CD332J J AA 3.3 kohms,1/6W
1 R80 VRG-ST2EG3R3J J AB 3.3 ohms,1/4W,Fusible
R101,102 VRD-MN2BD102J J AA 1 kohm,1/8W
R103,104 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R105,106 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R107,108 VRD-MN2BD473J J AA 47 kohms,1/8W
R109,110 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R111 VRD-MN2BD153J J AA 15 kohms,1/8W
R112 VRD-ST2CD153J J AA 15 kohms,1/6W
R113,114 VRD-ST2CD102J J AA 1 kohm,1/6W
R115,116 VRD-ST2CD560J J AA 56 ohms,1/6W
R117,118 VRD-MN2BD104J J AA 100 kohm,1/8W
R119,120 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R121,122 VRD-MN2BD333J J AA 33 kohms,1/8W
R123,124 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R125 VRD-MN2BD683J J AA 68 kohms,1/8W
R126,127 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R128,129 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R130,131 VRD-MN2BD152J J AA 1.5 kohms,1/8W
R132,133 VRD-MN2BD101J J AA 100 ohm,1/8W
R134,135 VRD-MN2BD103J J AA 10 kohm,1/8W
R136,137 VRD-ST2CD224J J AA 220 kohms,1/6W
R138 VRD-MN2BD103J J AA 10 kohm,1/8W
R139 VRD-ST2CD103J J AA 10 kohm,1/6W
R140 VRD-MN2BD473J J AA 47 kohms,1/8W
R141 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R142 VRD-ST2CD820J J AA 82 ohms,1/6W
R143 VRD-MN2BD473J J AA 47 kohms,1/8W
R144 VRD-MN2BD223J J AA 22 kohms,1/8W
R145 VRD-ST2CD4R7J J AA 4.7 ohms,1/6W
R146,147 VRD-MN2BD103J J AA 10 kohm,1/8W
R148 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R149 VRD-ST2EE151J J AA 150 ohms,1/4W
R158 VRD-ST2EE221J J AA 220 ohms,1/4W
R302 VRD-MN2BD100J J AA 10 ohm,1/8W
R309 VRD-ST2CD103J J AA 10 kohm,1/6W
R311 VRD-MN2BD104J J AA 100 kohm,1/8W
R313 VRD-MN2BD333J J AA 33 kohms,1/8W
R314 VRD-ST2CD220J J AA 22 ohms,1/6W
R316 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R322 VRD-MN2BD681J J AA 680 ohms,1/8W
R323 VRD-MN2BD683J J AA 68 kohms,1/8W
R325 VRD-MN2BD473J J AA 47 kohms,1/8W
R327 VRD-MN2BD330J J AA 33 ohms,1/8W
R336 VRD-MN2BD103J J AA 10 kohm,1/8W
R350 VRD-MN2BD272J J AA 2.7 kohms,1/8W
R351 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R352 VRD-MN2BD102J J AA 1 kohm,1/8W
R353 VRD-MN2BD271J J AA 270 ohms,1/8W
R355 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R356 VRD-MN2BD102J J AA 1 kohm,1/8W
R357 VRD-ST2CD474J J AA 470 kohms,1/6W
R358 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R359 VRD-MN2BD182J J AA 1.8 kohms,1/8W
R360 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R361,362 VRD-MN2BD153J J AA 15 kohms,1/8W
R363,364 VRD-MN2BD123J J AA 12 kohms,1/8W
R365 VRD-MN2BD103J J AA 10 kohm,1/8W
R372~374 VRD-MN2BD102J J AA 1 kohm,1/8W
R375 VRD-ST2CD471J J AA 470 ohms,1/6W
R376 VRD-MN2BD102J J AA 1 kohm,1/8W
R377 VRD-MN2BD473J J AA 47 kohms,1/8W
R378 VRD-MN2BD102J J AA 1 kohm,1/8W
R379 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R380 VRD-MN2BD152J J AA 1.5 kohms,1/8W
R381 VRD-MN2BD103J J AA 10 kohm,1/8W
R382 VRD-ST2EE151J J AA 150 ohms,1/4W
R383 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R384 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R385 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R386 VRD-ST2CD223J J AA 22 kohms,1/6W
R387 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R388 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R391,392 VRD-ST2EE271J J AA 270 ohms,1/4W
R393 VRD-MN2BD102J J AA 1 kohm,1/8W
R395 VRD-MN2BD473J J AA 47 kohms,1/8W
R561 VRD-MN2BD103J J AA 10 kohm,1/8W
R562 VRD-MN2BD824J J AA 820 kohms,1/8W
R563 VRD-ST2EE271J J AA 270 ohms,1/4W
R565 VRD-MN2BD333J J AA 33 kohms,1/8W
R566 VRD-ST2CD224J J AA 220 kohms,1/6W
R567 VRD-MN2BD683J J AA 68 kohms,1/8W
R568 VRD-MN2BD224J J AA 220 kohms,1/8W
R569 VRD-MN2BD104J J AA 100 kohm,1/8W
R570 VRD-ST2CD123J J AA 12 kohms,1/6W
R571 VRD-MN2BD394J J AA 390 kohms,1/8W
R572 VRD-MN2BD104J J AA 100 kohm,1/8W
R573 VRD-MN2BD563J J AA 56 kohms,1/8W
R574 VRD-MN2BD105J J AA 1 Mohm,1/8W
R575 VRD-MN2BD474J J AA 470 kohms,1/8W
R576 VRD-MN2BD225J J AA 2.2 Mohms,1/8W
R577 VRD-MN2BD154J J AA 150 kohms,1/8W
R578 VRD-MN2BD104J J AA 100 kohm,1/8W
R579 VRD-ST2CD153J J AA 15 kohms,1/6W
R580 VRD-MN2BD184J J AA 180 kohms,1/8W
R601~603 VRD-ST2CD102J J AA 1 kohm,1/6W
R604,605 VRD-MN2BD103J J AA 10 kohm,1/8W
R606,607 VRD-MN2BD392J J AA 3.9 kohms,1/8W
R608,609 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R610,611 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R612,613 VRD-MN2BD391J J AA 390 ohms,1/8W
R614,615 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R616 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R617 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R618,619 VRD-ST2CD331J J AA 330 ohms,1/6W
R620,621 VRD-MN2BD223J J AA 22 kohms,1/8W
R622,623 VRD-MN2BD224J J AA 220 kohms,1/8W
R690,691 VRD-MN2BD682J J AA 6.8 kohms,1/8W
R692,693 VRD-MN2BD333J J AA 33 kohms,1/8W
R702~704 VRD-ST2CD102J J AA 1 kohm,1/6W
R705~707 VRD-MN2BD102J J AA 1 kohm,1/8W
– 3 –
