Sharp CD-BK250W Service Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-BK250W/CD-BK2600W/CD-BK270W
R708~712 VRD-ST2CD102J J AA 1 kohm,1/6W
R713~717 VRD-MN2BD102J J AA 1 kohm,1/8W
R718~721 VRD-ST2CD102J J AA 1 kohm,1/6W
R724,725 VRD-ST2CD102J J AA 1 kohm,1/6W
R726~728 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R729 VRD-ST2CD102J J AA 1 kohm,1/6W
R731 VRD-MN2BD103J J AA 10 kohm,1/8W
R732,733 VRD-MN2BD102J J AA 1 kohm,1/8W
R734~736 VRD-ST2CD102J J AA 1 kohm,1/6W
R738 VRD-ST2CD223J J AA 22 kohms,1/6W
R739,740 VRD-ST2CD102J J AA 1 kohm,1/6W
R741 VRD-MN2BD102J J AA 1 kohm,1/8W
R746~748 VRD-MN2BD102J J AA 1 kohm,1/8W
R749~751 VRD-MN2BD104J J AA 100 kohm,1/8W
R752 VRD-MN2BD330J J AA 33 ohms,1/8W
R753 VRD-MN2BD102J J AA 1 kohm,1/8W
R754 VRD-MN2BD103J J AA 10 kohm,1/8W
R755 VRD-MN2BD102J J AA 1 kohm,1/8W
R756 VRD-MN2BD103J J AA 10 kohm,1/8W
R758~760 VRD-MN2BD103J J AA 10 kohm,1/8W
R761 VRD-MN2BD103J J AA 10 kohm,1/8W
R765 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R766~768 VRD-MN2BD103J J AA 10 kohm,1/8W
R769 VRD-ST2CD102J J AA 1 kohm,1/6W
R770 VRD-ST2CD103J J AA 10 kohm,1/6W
R771 VRD-MN2BD103J J AA 10 kohm,1/8W
R772 VRD-ST2CD103J J AA 10 kohm,1/6W
R773 VRD-ST2CD102J J AA 1 kohm,1/6W
R774 VRD-MN2BD103J J AA 10 kohm,1/8W
R777~779 VRD-MN2BD103J J AA 10 kohm,1/8W
R781 VRD-MN2BD473J J AA 47 kohms,1/8W
R782 VRD-MN2BD104J J AA 100 kohm,1/8W
R783 VRD-MN2BD101J J AA 100 ohm,1/8W
R901,902 VRD-ST2CD223J J AA 22 kohms,1/6W
R903 VRD-RT2HD332J J AA 3.3 kohms,1/2W
R904 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R905 VRD-ST2CD473J J AA 47 kohms,1/6W
R906 VRD-ST2CD100J J AA 10 ohm,1/6W
R907 VRD-ST2CD123J J AA 12 kohms,1/6W
R908 VRD-ST2EE561J J AA 560 ohms,1/4W
R909 VRD-ST2CD223J J AA 22 kohms,1/6W
R930 VRD-ST2CD104J J AA 100 kohm,1/6W
R931 VRD-MN2BD104J J AA 100 kohm,1/8W
R932,933 VRD-MN2BD563J J AA 56 kohms,1/8W
R934 VRD-MN2BD102J J AA 1 kohm,1/8W
R935 VRD-ST2CD102J J AA 1 kohm,1/6W
R936,937 VRD-MN2BD821J J AA 820 ohms,1/8W
R938,939 VRD-MN2BD563J J AA 56 kohms,1/8W
R940,941 VRD-MN2BD102J J AA 1 kohm,1/8W
R942 VRD-MN2BD223J J AA 22 kohms,1/8W
1 R943,944 VRG-ST2EC101J J AB 100 ohm,1/4W,Fusible
R945~948 VRN-VV3DAR22J J AC 0.22 ohms,2W
R949,950 VRN-VV3AAR10J J AB 0.1 ohm,1W
R951 VRD-MN2BD102J J AA 1 kohm,1/8W
R952 VRD-ST2CD102J J AA 1 kohm,1/6W
R953 VRD-MN2BD152J J AA 1.5 kohms,1/8W
R954 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R955~957 VRD-MN2BD563J J AA 56 kohms,1/8W
R958,959 VRD-ST2EE4R7J J AA 4.7 ohms,1/4W
R967,968 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R969 VRD-RT2HD4R7J J AA 4.7 ohms,1/2W
R970 VRD-RT2HD102J J AA 1 kohm,1/2W
R971 VRD-ST2CD683J J AA 68 kohms,1/6W
R972 VRD-ST2CD153J J AA 15 kohms,1/6W
R973 VRD-ST2CD473J J AA 47 kohms,1/6W
R977,978 VRD-ST2EE470J J AA 47 ohms,1/4W
R981,982 VRD-RT2HD681J J AA 680 ohms,1/2W
R983 VRD-ST2CD224J J AA 220 kohms,1/6W
R984 VRD-ST2CD473J J AA 47 kohms,1/6W
R986 VRD-RT2HD681J J AA 680 ohms,1/2W
R988 VRD-RT2HD681J J AA 680 ohms,1/2W
RD01 VRD-MN2BD681J J AA 680 ohms,1/8W
RD02 VRD-MN2BD821J J AA 820 ohms,1/8W
RD03 VRD-ST2CD102J J AA 1 kohm,1/6W
RD04 VRD-MN2BD152J J AA 1.5 kohms,1/8W
RD05 VRD-MN2BD222J J AA 2.2 kohms,1/8W
RD06 VRD-MN2BD272J J AA 2.7 kohms,1/8W
RD07 VRD-MN2BD392J J AA 3.9 kohms,1/8W
RD08 VRD-ST2CD562J J AA 5.6 kohms,1/6W
RD09 VRD-MN2BD103J J AA 10 kohm,1/8W
RD10 VRD-MN2BD183J J AA 18 kohms,1/8W
RD11 VRD-MN2BD333J J AA 33 kohms,1/8W
RD12 VRD-MN2BD104J J AA 100 kohm,1/8W
RD13 VRD-MN2BD681J J AA 680 ohms,1/8W
RD14 VRD-MN2BD821J J AA 820 ohms,1/8W
RD15 VRD-ST2CD182J J AA 1.8 kohms,1/6W
RD16 VRD-ST2CD392J J AA 3.9 kohms,1/6W
RD17 VRD-MN2BD184J J AA 180 kohms,1/8W
RD18 VRD-MN2BD681J J AA 680 ohms,1/8W
RD19 VRD-ST2CD821J J AA 820 ohms,1/6W
RD20 VRD-MN2BD102J J AA 1 kohm,1/8W
RD21 VRD-MN2BD152J J AA 1.5 kohms,1/8W
RD22 VRD-MN2BD222J J AA 2.2 kohms,1/8W
RD23 VRD-MN2BD272J J AA 2.7 kohms,1/8W
RD24 VRD-MN2BD392J J AA 3.9 kohms,1/8W
RD25 VRD-MN2BD562J J AA 5.6 kohms,1/8W
RD26 VRD-ST2CD103J J AA 10 kohm,1/6W
RD27 VRD-MN2BD183J J AA 18 kohms,1/8W
RD28 VRD-ST2CD333J J AA 33 kohms,1/6W
RD29 VRD-MN2BD104J J AA 100 kohm,1/8W
RD30 VRD-MN2BD562J J AA 5.6 kohms,1/8W
RK1 VRD-ST2CD103J J AA 10 kohm,1/6W
RK2,3 VRD-ST2CD563J J AA 56 kohms,1/6W
RK4 VRD-ST2CD103J J AA 10 kohm,1/6W
RK5 VRD-ST2CD102J J AA 1 kohm,1/6W
RK7 VRD-ST2CD102J J AA 1 kohm,1/6W
RK8 VRD-ST2CD562J J AA 5.6 kohms,1/6W
RK9~11 VRD-ST2CD102J J AA 1 kohm,1/6W
RK12 VRD-ST2CD101J J AA 100 ohm,1/6W
RK13 VRD-ST2CD122J J AA 1.2 kohms,1/6W
RK14,15 VRD-RT2HD101J J AA 100 ohm,1/2W
RK36,37 VRD-ST2CD391J J AA 390 ohms,1/6W
RK38 VRD-ST2CD101J J AA 100 ohm,1/6W
RK39,40 VRD-ST2CD102J J AA 1 kohm,1/6W
RK41,42 VRD-ST2CD103J J AA 10 kohm,1/6W
RK43 VRD-ST2CD183J J AA 18 kohms,1/6W
RK44,45 VRD-ST2CD682J J AA 6.8 kohms,1/6W
RK46 VRD-ST2CD183J J AA 18 kohms,1/6W
RK47 VRD-ST2CD822J J AA 8.2 kohms,1/6W
RK48 VRD-ST2CD103J J AA 10 kohm,1/6W
RK49,50 VRD-ST2CD103J J AA 10 kohm,1/6W
OTHER CIRCUITRY PARTS
BI4/CNS4 QCNWN1572AWZZ J AF Connector Ass’y,6/6Pin
BI102/CNS102 QCNWN1974AWZZ J Connector Ass’y,7/6Pin
BI601/CNS601 QCNWN1842AWZZ J AG Connector Ass’y,6/6Pin
BI701/CNS8 QCNWN1843AWZZ J AH Connector Ass’y,9/9Pin
BI902/CNS902 QCNWN1875AWZZ J AH Connector Ass’y,10/10Pin
BI903/CNS903 QCNWN2028AWZZ J Connector Ass’y,3/3Pin
[CD-BK270W Only]
BIK1/CNSK1 QCNWN1876AWZZ J Connector Ass’y,10/10Pin
CNP1 QCNCM704GAWZZ J AC Plug,7Pin
CNP2 QCNCM704HAWZZ J AC Plug,8Pin
CNP3 92LCONE6P53253 J AC Plug,6Pin
CNP4 QCNCM705FAFZZ J AB Plug,6Pin
CNP7 92LCONE6P53254 J AC Plug,6Pin
CNP8 92LCONE9P53254 J AD Plug,9Pin
CNP101 QCNCM705CAFZZ J AA Plug,3Pin
CNP301 92LCONE2P5268 J AB Plug,2Pin
CNP701 QCNCWZX32AWZZ J Socket,32Pin
CNP902 92LCONEAP5267 J AC Plug,10Pin
CNP971 92LCONE2P53253 J AB Plug,2Pin
CNP981 92LCONE5P52287 J AC Plug,5Pin
CNPK1 QCNCM705KAWZZ J AC Plug,10Pin
CNR1 92LCONE3P53253 J AB Plug,3Pin [CD-BK270W Only]
CNS1A/B QCNWN1537AWZZ J AG Connector Ass’y,7/7Pin
CNS2A/B QCNWN1538AWZZ J AG Connector Ass’y,8/8Pin
CNS3A/B QCNWN1539AWZZ J AE Connector Ass’y,6/6Pin
CNS701 QCNCWZF32AWZZ J Socket,32Pin
CNS702 QCNCWZY10AWZZ J Socket,10Pin
CNS971 QCNWN1389AWZZ J AC Connector Ass’y,2Pin
1 F901,902 QFS-D402CAWNI J AC Fuse,T4A L 250V
1 F903,904 QFS-D202CAWNI J AC Fuse,T2A L 250V
FFC701 QCNWN1878AWZZ J Flat Cable,32Pin
FFC702 QCNWN1845AWZZ J Flat Cable,10Pin
FL701 VVKBJ749GNK-1 J BD FL Display
FW981 QCNWN1836AWZZ J AD Flat Wire,5Pin
JK1 QJAKJ0007AWZZ J AF Jack,Mic
JK690 QSOCJ0219AWZZ J AD Jack,Video/AUX In
JK701 QJAKM0004AWZZ J AK Jack,Headphones
LG1 QLUGP0001AWZZ J AC Lug
1 LUG1,2 92LLUG1746A J AA Lug
M1 92LMTR2790CASY J BB Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
– 4 –
