Sharp CD-BK250W Service Manual

PRICE
RANK
DESCRIPTION
NO.
PARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-BK250W/CD-BK2600W/CD-BK270W
M3 92LTWMEN7E6Y J AR Motor with Worm Pulley
[T/T Up Down Loading]
M901 RMOTV0027AWZZ J AM Motor,Air Cooling Fan
PINK1 QLUGP0002AWZZ J AB Lug
RL914 RRLYD0016AWZZ J AH Relay
RX701 VHLN63H380A-1 J AK Remote Sensor,N63H380A
SO302 QTANC0206AWZZ J AD FM Antenna Terminal
SO901 QTANA0417AWZZ J AE Terminal,Speaker
SR1 QTANA0420AWZZ J Terminal,Surround Speaker
[CD-BK270W Only]
SW1 SWMPU10780MLB J AH Switch,Push Type [Open/Close]
SW2 SWMPU11470MLB J AE Switch,Push Type [Clamp]
SW3 SWMPU11470MLB J AE Switch,Push Type [Disc Number]
SW4 QSWF9001AW01 J AD Switch,Push Type [Pickup In]
SW601 QSW-S0024AWZZ J AE Switch,Slide Type [Span Selector]
SW701 92LSWICHT1663T J AC Switch,Key Type [On/Stand-by]
SW702 92LSWICHT1663T J AC Switch,Key Type [Clock]
SW703 92LSWICHT1663T J AC Switch,Key Type [Timer/Sleep]
SW712 92LSWICHT1663T J AC Switch,Key Type [Disc Skip]
SW713 92LSWICHT1663T J AC Switch,Key Type [Open/Close]
SW714 92LSWICHT1663T J AC Switch,Key Type [Dimmer]
SW715 92LSWICHT1663T J AC Switch,Key Type [X-Bass/Demo]
SW716 92LSWICHT1663T J AC Switch,Key Type [Equalizer]
SW717 92LSWICHT1663T J AC Switch,Key Type [Volume Up]
SW718 92LSWICHT1663T J AC Switch,Key Type [Volume Down]
SW719 92LSWICHT1663T J AC Switch,Key Type [Reverse Mode]
SW720 92LSWICHT1663T J AC Switch,Key Type [CD]
SW721 92LSWICHT1663T J AC Switch,Key Type [Tape]
SW722 92LSWICHT1663T J AC Switch,Key Type [Tuning Down]
SW723 92LSWICHT1663T J AC Switch,Key Type [Memory/Set]
SW724 92LSWICHT1663T J AC Switch,Key Type [Rewind]
SW725 92LSWICHT1663T J AC Switch,Key Type [Fast forward]
SW726 92LSWICHT1663T J AC Switch,Key Type [Play]
SW727 92LSWICHT1663T J AC Switch,Key Type [Stop]
SW728 92LSWICHT1663T J AC Switch,Key Type [Reverse Play]
SW729 92LSWICHT1663T J AC Switch,Key Type [Rec/Pause]
SW730 92LSWICHT1663T J AC Switch,Key Type [Tuning Up]
SW731 92LSWICHT1663T J AC Switch,Key Type [Video/Aux]
SW732 92LSWICHT1663T J AC Switch,Key Type [Tuner (Band)]
1 SW801 QSOCE0009AWZZ J AH Switch,Slide Type
[Voltage Selector]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0080AWZZ J AC Rail,Guide
304 NSFTM0020AWFW J AD Shaft,Guide
305 92LM-CUSN1524A J AC Cushion
1 306 92LHPC1LXASY J BD Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×3.8×0.25mm
M1 92LMTR2790CASY J BB Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
CABINET PARTS
201 92LCAB3563AASY J Front Panel Ass’y
[For CD-BK250W]
201 92LCAB3567AASY J Front Panel Ass’y
[For CD-BK2600W]
201 92LCAB3747AASY J Front Panel Ass’y
[For CD-BK270W]
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 GDORF0099AWSA J AE Holder,Cassette [Tape 1]
201- 3 GDORF0100AWSA J AE Holder,Cassette [Tape 2]
201- 4 GCOVA1349AWSA J AG Cover,Cassette [Tape 1]
[For CD-BK250W/CD-BK270W]
201- 4 GCOVA1349AWSB J AH Cover,Cassette [Tape 1]
[For CD-BK2600W]
201- 5 GCOVA1388AWSA J Cover,Cassette [Tape 2]
[For CD-BK250W/CD-BK270W]
201- 5 GCOVA1388AWSB J Cover,Cassette [Tape 2]
[For CD-BK2600W]
201- 6 HDECQ0686AWSA J AE Panel,Cassette [Tape 1]
201- 7 HDECQ0687AWSA J AE Panel,Cassette [Tape 2]
201- 8 HDECQ0748AWSA J Panel,Amp. [For CD-BK250W]
201- 8 HDECQ0749AWSA J Panel,Amp. [For CD-BK2600W]
201- 8 HDECQ0775AWSA J Panel,Amp. [For CD-BK270W]
201- 9 JKNBZ0808AWSA J AE Button,Power
[For CD-BK250W/CD-BK270W]
201- 9 JKNBZ0808AWSB J AE Button,Power [For CD-BK2600W]
201-10 JKNBZ0778AWSA J AF Button,Dimmer/Tuning
[For CD-BK250W/CD-BK270W]
201-10 JKNBZ0778AWSB J AG Button,Dimmer/Tuning
[For CD-BK2600W]
201-11 JKNBZ0779AWSA J AF Button,Function
201-12 HDECQ0690AWSA J AC Volume Ring
201-13 JKNBZ0780AWSA J AF Button,Disc Control
[For CD-BK250W/CD-BK270W]
201-13 JKNBZ0780AWSB J AF Button,Disc Control
[For CD-BK2600W]
201-14 JKNBZ0804AWSA J Button,Center Operation
201-15 GCOVA1351AWSA J AB Cover,Operation LED A
201-16 MLIFP0008AWZZ J AD Damper
201-17 MSPRD0092AWFJ J AB Spring,Cassette [Tape 1]
201-18 MSPRD0093AWFJ J AB Spring,Cassette [Tape 2]
201-19 JKNBZ0783AWSA J AF Button,X-Bass/Equalizer
201-20 PSHEP0063AWZZ J AB Filter,Remote Sensor
201-21 LHLDZ1328AWZZ J AC Holder,Cassette Lock
201-22 MSPRC0029AWFJ J AB Spring,Cassette Lock
201-23 MLOKC0006AWZZ J AB Lock Lever Cassette [Tape 1]
201-24 MLOKC0007AWZZ J AB Lock Lever Cassette [Tape 2]
201-25 JKNBZ0805AWSA J AE Button,Volume
201-26 92LBADGE1671A J AC Badge,SHARP
202 92LCAB3561BASY J AN Side Panel Ass’y,Left
[For CD-BK250W/CD-BK270W]
202 92LCAB3565BASY J AN Side Panel Ass’y Left
[For CD-BK2600W]
202- 1 ———— — Side Panel,Left
(Not Replacement Item)
202- 2 PCUSG0022AWZZ J AB Cushion,Leg
203 92LCAB3561CASY J AN Side Panel Ass’y,Right
[For CD-BK250W/CD-BK270W]
203 92LCAB3565CASY J AN Side Panel Ass’y Right
[For CD-BK2600W]
203- 1 ———— — Side Panel,Right
(Not Replacement Item)
203- 2 PCUSG0022AWZZ J AB Cushion,Leg
204 GCAB-1194AWSA J AP Cabinet,Top
[For CD-BK250W/CD-BK270W]
204 GCAB-1194AWSB J AP Cabinet,Top [For CD-BK2600W]
205 JKNBK0012AWSG J AK Knob,Karaoke
206 GCOVA1348AWSA J AH Cover,CD Tray
207 GITAR0736AWSA J Rear Panel [For CD-BK250W]
207 GITAR0737AWSA J Rear Panel [For CD-BK2600W]
207 GITAR0784AWSA J Rear Panel [For CD-BK270W]
211 LANGK0252AWFW J AE Bracket,Fan Support
212 LBSHC0002AWZZ J AD Bushing,AC Power Supply Cord
213 LCHSM0122AWFW J AN Chassis,Main
214 LHLDZ1332AWZZ J AD Holder,FL Display
215 TSPC-0887AWZZ J Label,Specifications
[CD-BK250W for Taiwan]
215 TSPC-0888AWZZ J Label,Specifications
[CD-BK250W for Thailand]
215 TSPC-0889AWZZ J Label,Specifications
[CD-BK250W Except for
Taiwan/Thailand]
215 TSPC-0893AWZZ J Label,Specifications
[CD-BK2600W for Taiwan]
215 TSPC-0894AWZZ J Label,Specifications
[CD-BK2600W for Thailand]
215 TSPC-0895AWZZ J Label,Specifications
[CD-BK2600W Except for
Taiwan/Thailand]
215 TSPC-0943AWZZ J Label,Specifications
[CD-BK270W for Taiwan]
215 TSPC-0944AWZZ J Label,Specifications
[CD-BK270W for Thailand]
215 TSPC-0945AWZZ J Label,Specifications
[CD-BK270W Except for
Taiwan/Thailand]
218 NFANP0001AWZZ J AD Rotary Fan
219 PCUSG0022AWZZ J AB Cushion,Leg
220 PRDAR0188AWFW J AR Heat Sink,Main
1 222 QACCA0003AW00 J AL AC Power Supply Cord
– 5 –
