– 13 –
CD-CH1000
1. Motor assembly (X 2) mounting (screw x 4) 101/129 Fig.14
2. MT idle gear mounting (screw x 1) 125 Fig.14
3. MT system gear assembly 123/124/126/127 Fig.14
4. STB/tray drive system gear and others assembling/ 137/138/145/146 (153)/147/148 Fig.14
mounting (screw X 3)
5. Tray big gear assembly 131 Fig.14 Gear positioning
6. T.M SW PWB mounting (screw x 3) Fig.15
7. STB holder assembling 103 Fig.14
8. STB drive gear L/R assembly mounting (screw x 2) 111 (110)/112 (110) Fig.14
9. Tray joint gear R/tray drive gear R assembling 134/136 Fig.15 Gear positioning
10. Tray gear A/B assembling 132/133 Fig.15 Gear positioning
11. Lift gear B/C assembling 143/144 Fig.16 Gear positioning
12. MT idler gear F assembling, mode big gear 128/142 Fig.16
mounting (screw x 1)
13. Change box R mounting (screw x 4) 104 Fig.16
14. Lift gear A assembling 142 Fig.16 Gear positioning
15. Change box L assembly mounting (screw x 4) 102/130/135 Fig.17
16. Lift cam assembling (shaft inserting) 144 Fig.17 Gear positioning
17. STB holder height adjusting Fig.18 Check/adjustment
18. Top plate F/disc OB LEV. mounting (screw x 6) 180 Fig.18
19. Trays 1 - 6 assembling 191/192/193/194/195/196 Fig.19
20. Top plate R mounting (screw x 6) -
Applied part No.
Work content
Assembly fig. No.
Remarks
CD CHANGER MECHANISM MAIN BASE PARTS ASSEMBLING/ADJUSTING
PROCEDURE
101 MAIN BASE
102 CHANCE BOX L
103 STB HOLDER
104 CHANGE BOX R
110 STB DRIVE GEAR A
111 STB DRIVE GEAR L
112 STB DRIVE GEAR R
120 STABILIZER FH
123 MT IDLER GEAR A
124 MT IDLER GEAR B
125 MT IDLER GEAR C
126 MT IDLER GEAR D
127 MT IDLER GEAR E
128 MT IDLER GEAR F
129 MOTOR GEAR
130 TRAY DRIVE GEAR F
131 TRAY BIG GEAR
132 TRAY GEAR A
133 TRAY GEAR B
134 TRAY DRIVE GEAR R
135 TRAY JOINT GEAR F
136 TRAY JOINT GEAR R
137 TRAY GEAR C
138 TRAY IDLER GEAR
Part name
No.
140 LIFT CAM
141 MODE BIG GEAR
142 LIFT GEAR A
143 LIFT GEAR B
144 LIFT GEAR C
145 STB GEAR A
146 STB GEAR B
147 STB GEAR C
148 STB GEAR D
150 LIFT LEVER
151 TRAY LOCK LEVER
152 DISC OB LEVER
153 STB GEAR ANG.
180 TOP PLATE F
181 TOP PLATE R
191 TRAY T1
192 TRAY T2
193 TRAY T3
194 TRAY T4
195 TRAY T5
196 TRAY T6
Part nameNo.
CD CHANGER MECHANISM PARTS LIST
