PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-CH1000
201-32 MSPRZ0010AWFJ J Spring,Display PWB
201-33 JKNBK0080AWSA J AG Knob,Jog
201-34 PSPAZ0025AWZZ J Spacer,LCD PWB
201-35 LHLDZ1265AWZZ J AC Holder,LED,A
201-36 LHLDZ1266AWZZ J AC Holder,LED,B
201-37 PSHEP0040AWZZ J AG Sheet,LCD
201-38 LHLDZ1263AWZZ J AE Holder,LCD
202 92LCAB3435BASY J Side Panel Ass’y,Left
202- 1 GITAS0077AWSA J AP Side Panel,Left
202- 2 PCUSG0022AWZZ J AB Cushion,Leg,Left
203 92LCAB3435CASY J Side Panel Ass’y,Right
203- 1 GITAS0078AWSA J AP Side Panel,Right
203- 2 PCUSG0022AWZZ J AB Cushion,Leg,Right
204 GCAB-1188AWSA J AN Top Cabinet
205 92LPNL3435AASY J Control Panel Ass’y
205- 1 GCOVA1311AWSA J AN Control Panel A
205- 2 GCOVA1312AWSA J AB Indicator A,Button
205- 3 GCOVA1313AWSA J AB Indicator B,Button
205- 4 GDORF0082AWSA J AQ Control Panel B
205- 5 HDECQ0601AWSA J AM Decoration Plate,Outer Window
205- 6 HDECQ0602AWSA J AG Outer Window
205- 7 HDECQ0603AWSA J AG Inner Window
205- 8 HDECQ0604AWSA J AG Ring,Jog Knob
205- 9 JKNBZ0727AWSA J AH Button,Function
205-10 JKNBZ0728AWSA J AH Button,Control
205-11 JKNBZ0730AWSA J AG Button,Play Mode
205-12 JKNBZ0731AWSA J AG Button,Menu
205-13 JKNBZ0732AWSA J AE Button,Enter
205-14 MSPRD0142AWFJ J AD Spring,Control Panel
205-15 LHLDZ1267AWZZ J AD Holder,LED,C
205-16 LHLDZ1268AWZZ J AC Holder,LED,D
206 GEAR3435AASY1 J Gear Ass’y
206- 1 LHLDZ1261AWZZ J AE Gear Box A
206- 2 LHLDZ1262AWZZ J AC Gear Box B
206- 3 PSPAZ0023AWZZ J AC Spacer,Warm Gear
206- 4 NGERH0097AWZZ J AC Gear,Reduc.A
206- 5 NGERH0124AWZZ J AF Gear,Reduc.B
206- 6 NGERW0013AWZZ J AC Gear,Warm
206- 7 NGERW0014AWZZ J AF Gear,Warm Wheel
207 GITAR0610AWSA J AP Rear Panel [For U.S.A.]
207 GITAR0642AWSA J Rear Panel [For Canada]
208 HDECQ0605AWSA J AP Decoration Plate,
Display Window
209 LANGK0197AWFW J AG Bracket,Center Support
210 LANGK0198AWFW J AE Bracket,Fan Motor Support
211 LANGK0199AWFW J AF Bracket,Heat Sink Support
212 LANGK0200AWFW J AE Bracket,PWB Support
213 LANGK0226AWFW J Bracket,Panel Support,Left
214 LANGK0227AWFW J Bracket,Panel Support,Right
215 LANGT0042AWFW J AC Bracket,Power PWB/Main PWB
! 216 LBSHC0005AWZZ J AD Bushing,AC Power Supply Cord
217 LCHSM0105AWFW J AW Main Chassis
218 LCHSZ0017AWFW J AN Chassis,Bottom
219 LHLDK9001AW00 J AB Poly Core Tie
225 MSPRD0108AWFJ J AC Spring,Fan Motor
226 NBRGC0003AWZZ J AC Bearing Metal
227 NFANP0001AWZZ J AD Rotary Fan,Motor
228 PCUSG0008AWZZ J AB Cushion,Spacer
229 PCUSG0022AWZZ J AB Cushion,Leg
! 230 PRDAR0163AWFW J AP Heat Sink,Main
! 231 PRDAR0164AWFW J AS Heat Sink,Sub A
! 232 PRDAR0165AWFW J AH Heat Sink,Sub B
233 92LNBAND1318A J AA Nylon Band,80mm
236 PSLDM3075AWFW J Shield Plate,Power PWB
237 PSLDM3076AWFW J Shield Plate,Phone
238 PSPAS0003AWZZ J AC Spacer,Fan Motor Support
Bracket
! 239 QACCD0022AWZZ J AM AC Power Supply Cord
! 240 QFSHD0001AWZZ J AB Holder,Fuse
241 92LCSPR1431C J AA Spring,Fan Ring
250 KMECB0015AWZZ J BB Tape Mechanism Ass’y
250- 1 92PF513-869 J Head Plate Block
250- 2 92PF525-332 J Motor with Pulley [Tape]
250- 3 92PF567-648 J Tape Mechanism PWB Ass’y
250- 4 92PFF19U- J Belt,Main
250- 5 92PF514-135 J Pinch Roller
250- 6 92PFF19S- J Belt,FF/REW
250- 7 92PFD58M-XX J Gear,Cam
250- 8 92PF765-286 J Solenoid
601 LX-BZ0880AFZZ J AC Screw,ø2×2.2mm
602 LX-BZ2222AXZZ J AB Screw,Special
603 LX-EZ0028AWFN J AC Screw,ø2.6×12mm
604 LX-HZ0082AFZZ J AA Screw,ø4×8mm
605 LX-JZ0010AFFD J AA Screw,ø3×10mm
606 XBBSD20P05000 J AA Screw,ø2×5mm
607 XEBSD26P10000 J AA Screw,ø2.6×10mm
608 XEBSD30P10000 J AA Screw,ø3×10mm
609 XEBSD30P14000 J AA Screw,ø3×14mm
610 XEBSD30P20000 J AA Screw,ø3×20mm
611 XESSD26P12000 J AB Screw,ø2.6×12mm
612 XESSD30P10000 J AA Screw,ø3×10mm
613 XESSN26P12000 J Screw,ø2.6×12mm
614 XJBSD30P08000 J AA Screw,ø3×8mm
615 XJBSD30P10000 J AA Screw,ø3×10mm
616 XJBSD30P14000 J AA Screw,ø3×14mm
617 XJBSF30P10000 J AA Screw,ø3×10mm
618 XJBSF30P16000 J AA Screw,ø3×16mm
619 XJSSD30P10000 J AA Screw,ø3×10mm
620 XWHSD32-10130 J AA Washer,ø3.2×ø13×1.0mm
PACKING PARTS (Except for U.S.A.)
SPAKA0258AWZZ J Packing Add.,Left/Right (Serial
No.00600001~00704000 Only)
SPAKA0268AWZZ J Packing Add.,Front/Rear (Serial
No.00704001~)
SPAKC1041AWZZ J Packing Case
[Except for Canada]
SPAKC1042AWZZ J Packing Case [For Canada]
SPAKZ0629AWZZ J Packing Add.,Accessories (Serial
No.00600001~00704000 Only)
SSAKA0007AWZZ J AB Polyethylene Bag,Accessories
(Serial No.007040001~)
SSAKH0038AWZZ J AE Polyethylene Bag,Unit
TLABN0112AWZZ J AA Label,Serial Number
[For Canada Only]
TLABR1142AWZZ J AB Label,Bar Code,Packing Case
92LBAG1460C1 J AB Polyethylene Bag,Accessories
(Serial No.00600001~
00704000 Only)
ACCESSORIES
QANTL0007AWZZ J AK AM/FM Loop Antenna
TCAUS0042AWZZ J AB Caution,Sheet
TINSE0319AWZZ J AG Operation Manual [For U.S.A.]
TINSK0106AWZZ J AK Operation Manual [For Canada]
TINSZ0585AWZZ J AB Quick Guide [U.S.A.Only]
TLABN0100AWZZ J Label,Prod.Serial Number
[For U.S.A.Only]
TLABZ0593AWZZ J AB Energy Star Label (Set)
TLABZ0818AWZZ J Label,Feature,CD Changer
RRMCG0240AWSA J AU Remote Control
GFTAB1030AWSA J Battery Lid,Remote Control
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A 92LPWB3435MANS J — Main
PWB-B1~9 92LPWB3435DPLS J — Display/LED A/LED B/
CD Switch/Control/Jog/Motor/
Switch/Headphones
(Combined Ass’y)
PWB-C 92LPWB3435CDUS J — CD
PWB-D1~3 92LPWB3435PWRS J — Power/Sub Trans/Speaker
(Combined Ass’y)
PWB-E QPWBF0027AWZZ J AD CD Motor (PWB Only)
PWB-F QPWBF0644AWZZ J AD Tray Switch (PWB Only)
PWB-G QPWBF0645AWZZ J AC Cam Switch (PWB Only)
PWB-H 92PF567-648 J — Tape Mechanism
OTHER SERVICE PARTS
QCNWN6931AFZZ J Extension Flat Cable (33Pin)
UDSKA0004AFZZ J AZ CD Pickup Lens Cleaner Disc
– 7 –
