Sharp CD-CH1000 User Manual

PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-CH1000
– 5 –
R934 VRD-ST2CD102J J AA 1 kohm,1/6W
R935,936 VRS-CY1JB102J J AA 1 kohm,1/16W
R941 VRS-CY1JB334J J AA 330 kohms,1/16W
R943,944 VRS-CY1JB102J J AA 1 kohm,1/16W
R945 VRS-CY1JB101J J AA 100 ohm,1/16W
R946~948 VRD-ST2CD102J J AA 1 kohm,1/6W
R949 VRS-CY1JB102J J AA 1 kohm,1/16W
R953,954 VRD-ST2CD102J J AA 1 kohm,1/6W
R955~959 VRS-CY1JB102J J AA 1 kohm,1/16W
R960 VRD-ST2CD102J J AA 1 kohm,1/6W
R962,963 VRS-CY1JB102J J AA 1 kohm,1/16W
R965,966 VRD-ST2CD102J J AA 1 kohm,1/6W
R967 VRS-CY1JB102J J AA 1 kohm,1/16W
R968~970 VRD-ST2CD102J J AA 1 kohm,1/6W
R971 VRS-CY1JB102J J AA 1 kohm,1/16W
R972 VRD-ST2CD102J J AA 1 kohm,1/6W
R974 VRS-CY1JB102J J AA 1 kohm,1/16W
R976~981 VRS-CY1JB102J J AA 1 kohm,1/16W
R982,983 VRD-ST2CD102J J AA 1 kohm,1/6W
R984~988 VRS-CY1JB102J J AA 1 kohm,1/16W
R989 VRD-ST2CD102J J AA 1 kohm,1/6W
R990 VRS-CY1JB102J J AA 1 kohm,1/16W
R991 VRD-ST2CD102J J AA 1 kohm,1/6W
R992~994 VRS-CY1JB102J J AA 1 kohm,1/16W
R995 VRD-ST2CD102J J AA 1 kohm,1/6W
R996~998 VRS-CY1JB102J J AA 1 kohm,1/16W
R999 VRD-ST2CD102J J AA 1 kohm,1/6W
R1001 VRS-CY1JB473J J AA 47 kohms,1/16W
R1002 VRS-CY1JB104J J AA 100 kohm,1/16W
R1003 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R1007 VRS-CY1JB102J J AA 1 kohm,1/16W
R1008 VRD-ST2CD102J J AA 1 kohm,1/6W
R1011 VRS-CY1JB104J J AA 100 kohm,1/16W
R1012 VRS-CY1JB102J J AA 1 kohm,1/16W
R1013 VRD-ST2CD473J J AA 47 kohms,1/6W
R1014 VRS-CY1JB104J J AA 100 kohm,1/16W
R1015 VRS-CY1JB821J J AA 820 ohms,1/16W
R1016,1017 VRS-CY1JB103J J AA 10 kohm,1/16W
R1022 VRS-CY1JB473J J AA 47 kohms,1/16W
R1023 VRS-CY1JB102J J AA 1 kohm,1/16W
R1024 VRS-CY1JB103J J AA 10 kohm,1/16W
R1026,1027 VRS-CY1JB103J J AA 10 kohm,1/16W
R1028 VRS-CY1JB273J J AA 27 kohms,1/16W
R1031,1032 VRS-CY1JB102J J AA 1 kohm,1/16W
R1035,1036 VRS-CY1JB562J J AA 5.6 kohms,1/16W
R1040 VRS-CY1JB103J J AA 10 kohm,1/16W
R1044 VRS-CY1JB223J J AA 22 kohms,1/16W
R1046 VRS-CY1JB123J J AA 12 kohms,1/16W
R1048 VRS-CY1JB103J J AA 10 kohm,1/16W
R1050~1052 VRS-CY1JB102J J AA 1 kohm,1/16W
R1053~1057 VRS-CY1JB103J J AA 10 kohm,1/16W
R1058 VRS-CY1JB104J J AA 100 kohm,1/16W
R1060 VRS-CY1JB104J J AA 100 kohm,1/16W
R1065,1066 VRS-CY1JB103J J AA 10 kohm,1/16W
R1068 VRD-ST2CD103J J AA 10 kohm,1/6W
R1071,1072 VRD-ST2CD333J J AA 33 kohms,1/6W
R1081,1082 VRS-CY1JB562J J AA 5.6 kohms,1/16W
R1084~1090 VRS-CY1JB562J J AA 5.6 kohms,1/16W
R1092~1094 VRS-CY1JB562J J AA 5.6 kohms,1/16W
R1099 VRD-ST2CD473J J AA 47 kohms,1/6W
R1105 VRD-ST2CD103J J AA 10 kohm,1/6W
R1106~1109 VRS-CY1JB103J J AA 10 kohm,1/16W
R1112,1113 VRS-CY1JB123J J AA 12 kohms,1/16W
R1118,1119 VRS-CY1JB102J J AA 1 kohm,1/16W
R1124~1126 VRS-CY1JB103J J AA 10 kohm,1/16W
R1129,1130 VRS-CY1JB472J J AA 4.7 kohms,1/16W
R1131,1132 VRS-CY1JB221J J AA 220 ohms,1/16W
R1133 VRD-ST2CD471J J AA 470 ohms,1/6W
R1138,1139 VRS-CY1JB564J J AA 560 kohms,1/16W
R1140 VRD-ST2EE2R2J J AA 2.2 ohms,1/4W
R1141 VRD-ST2CD102J J AA 1 kohm,1/6W
R1142 VRD-ST2EE2R2J J AA 2.2 ohms,1/4W
R1143 VRD-ST2CD105J J AA 1 Mohm,1/6W
RA710,711 VRD-ST2CD151J J AA 150 ohms,1/6W
OTHER CIRCUITRY PARTS
BI201A/B QCNWN1658AWZZ J AF Connector Ass’y,8/8Pin
BI702/CNS702 QCNWN1668AWZZ J AF Connector Ass’y,6/6Pin
BI703A/B QCNWN1674AWZZ J AD Connector Ass’y,2/2Pin
BI720/CNS720 QCNWN1665AWZZ J AH Connector Ass’y,11/11Pin
BI730/CNS730 QCNWN1675AWZZ J AE Connector Ass’y,4/4Pin
BI740A/B QCNWN1673AWZZ J AE Connector Ass’y,3/3Pin
BI741/CNS741 QCNWN1666AWZZ J AG Connector Ass’y,5/5Pin
BI770/CNS770 QCNWN1667AWZZ J AG Connector Ass’y,7/7Pin
BI771A/B QCNWN1684AWZZ J AE Connector Ass’y,4/4Pin
BI772/CNS772 QCNWN1683AWZZ J AG Connector Ass’y,6/6Pin
BI773/CNS773 QCNWN1682AWZZ J AD Connector Ass’y,2/2Pin
BI804/CNS804 QCNWN1656AWZZ J AE Connector Ass’y,6/6Pin
BI808/CNS808 QCNWN1655AWZZ J AE Connector Ass’y,5/5Pin
BI940/CNS940 QCNWN1661AWZZ J AF Connector Ass’y,8/8Pin
BI950 QCNCW010HAWZZ J AD Socket,8Pin
BI960 QCNCW010QAWZZ J AE Socket,15Pin
CNP1 QCNCWZF33AWZZ J AF Socket,33Pin
CNP2 QCNCW026HAWZZ J AC Socket,8Pin
CNP3 QCNCW026DAWZZ J AC Socket,4Pin
CNP4 92LCONE4P53254 J AC Plug,4Pin
CNP5 QCNCM704HAWZZ J AC Plug,8Pin
CNP6 92LCONE6P53253 J AC Plug,6Pin
CNP6A 92LCONE6P53254 J AC Plug,6Pin
CNP7 QCNCM704GAWZZ J AC Plug,7Pin
CNP101 QCNCM704GAFZZ J AC Plug,7Pin
CNP102 QCNCM704HAFZZ J AC Plug,8Pin
CNP203 92LCONE5P5268 J AD Plug,5Pin
CNP204 92LCONE2P53254 J AB Plug,2Pin
CNP207 92LCONE4P53254 J AC Plug,4Pin
CNP303 92LCONE3P5268 J AC Plug,3Pin
CNP701 QCNCWZG05AWZZ J AB Socket,5Pin
CNP721 92LCONE6P53254 J AC Plug,6Pin
CNP775 92LCONE2P53253 J AB Plug,2Pin
CNP801 QCNCM049BAWZZ J AC Plug,2Pin
CNP802 QCNCM051EAWZZ J AD Plug,5Pin
CNP803 QCNCM035CAWZZ J AB Plug,3Pin
CNP805 92LCONE6P5268 J AC Plug,6Pin
CNP806 QCNCM010QAWZZ J AD Plug,15Pin
CNP807 QCNCM010HAWZZ J AC Plug,8Pin
CNP901 QCNCWZF33AWZZ J AF Socket,33Pin
CNP931 92LCONPB11BPHK J AC Plug,11Pin
CNP933 92LCONE5P53253 J AB Plug,5Pin
CNP934 92LCONE7P53253 J AC Plug,7Pin
CNP935A 92LCONPB6BPHK J AB Plug,6Pin
CNP970 QCNCWZG11AWZZ J AD Socket,11Pin
CNS4 QCNWN1692AWZZ J AD Connector Ass’y,4Pin
CNS5A/B QCNWN1690AWZZ J AG Connector Ass’y,8/8Pin
CNS6A/B QCNWN1668AWZZ J AF Connector Ass’y,6/6Pin
CNS7A/B QCNWN1689AWZZ J AF Connector Ass’y,7/7Pin
CNS200 QCNWN1659AWZZ J AC Connector Ass’y,2Pin
COR801 RCORF0015AWZZ J AB Core
CORE1 RCORF0015AWZZ J AB Core
! F801 QFS-D252BSJNI J AB Fuse,2.5A 125V
! F803,804 QFS-D502BSJNI J AE Fuse,5A 125V
! F805,806 QFS-D402BSJNI J AB Fuse,4A 125V
! F807 QFS-D502BSJNI J AE Fuse,5A 125V
! F808 QFS-D252BSJNI J AB Fuse,2.5A 125V
FFC901 QCNWN1672AWZZ J AF Flat Cable,33Pin
FFC970 QCNWN1671AWZZ J AE Flat Cable,11Pin
FW2 QCNWN1691AWZZ J AD Flat Wire,8Pin
FW3 QCNWN1693AWZZ J AC Flat Wire,4Pin
JK501 92LJACKL1776A J AF Jack,AUX IN
JK701 QJAKM0010AWZZ J AF Jack,Headphones
JOG701 QSW-Z0011AWZZ J AG Switch,Push Type [Jog Dial]
LCD720 RUNTZ0020AWZZ J BC LCD Display
MO200 RMOTV0027AWZZ J AM Motor,Air Cooling Fan
MO700 RMOTV0027AWZZ J AM Motor,Control Panel
MOB1 92LMTR3435DASY J AM Main Cam Motor Ass’y
MOB2 92LMTR3435DASY J AM Tray Motor Ass’y
NM1 92LMTR2996CASY J AS Motor with Chassis [Spindle]
NM2 92LMTR1854BASY J AP Motor with Gear [Sled]
NSW1 QSW-F9001AW01 J AD Switch,Push Type [Pickup In]
RX701 VHLN64H380A-1 J AK Remote Sensor,N64H380A
! RY201,202 RRLYD0004AWZZ J AP Relay
! RY801 RRLYD0001SJZZ J AQ Relay
SO201 QTANA0806AWZZ J AG Terminal,Speaker
SW701 92LSWICH1401AT J AC Switch,Key Type [Power]
SW705 QSW-B0002AWZZ J AF Switch,Lever Type [Open/Close]
SW710 92LSWICH1401AT J AC Switch,Key Type
[Panel Open/Close]
SW711 92LSWICH1401AT J AC Switch,Key Type [Volume Down]
SW712 92LSWICH1401AT J AC Switch,Key Type [Volume Up]
SW720 92LSWICH1401AT J AC Switch,Key Type [CD1 Eject]
SW721 92LSWICH1401AT J AC Switch,Key Type [CD2 Eject]
SW722 92LSWICH1401AT J AC Switch,Key Type [CD3 Eject]
SW723 92LSWICH1401AT J AC Switch,Key Type [CD4 Eject]
SW724 92LSWICH1401AT J AC Switch,Key Type [CD5 Eject]
