NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-CH1000
– 6 –
SW725 92LSWICH1401AT J AC Switch,Key Type [CD6 Eject]
SW730 92LSWICH1401AT J AC Switch,Key Type [CD1 Play]
SW731 92LSWICH1401AT J AC Switch,Key Type [CD2 Play]
SW732 92LSWICH1401AT J AC Switch,Key Type [CD3 Play]
SW733 92LSWICH1401AT J AC Switch,Key Type [CD4 Play]
SW734 92LSWICH1401AT J AC Switch,Key Type [CD5 Play]
SW735 92LSWICH1401AT J AC Switch,Key Type [CD6 Play]
SW750 92LSWICH1401AT J AC Switch,Key Type [Record Pause]
SW751 92LSWICH1401AT J AC Switch,Key Type [Clear]
SW752 92LSWICH1401AT J AC Switch,Key Type [Memory]
SW753 92LSWICH1401AT J AC Switch,Key Type [Fast Reverse]
SW755 92LSWICH1401AT J AC Switch,Key Type [Fast Forward]
SW756 92LSWICH1401AT J AC Switch,Key Type [Play/Pause]
SW758 92LSWICH1401AT J AC Switch,Key Type [Stop]
SW761 92LSWICH1401AT J AC Switch,Key Type [AUX]
SW762 92LSWICH1401AT J AC Switch,Key Type [Tuner]
SW763 92LSWICH1401AT J AC Switch,Key Type [Tape]
SW764 92LSWICH1401AT J AC Switch,Key Type [CD]
SW770 92LSWICH1401AT J AC Switch,Key Type [Play Mode]
SW772 92LSWICH1401AT J AC Switch,Key Type
[Equalizer Mode]
SW773 92LSWICH1401AT J AC Switch,Key Type [X-BASS]
SW774 92LSWICH1401AT J AC Switch,Key Type [Display]
SW776 92LSWICH1401AT J AC Switch,Key Type [Menu]
SW778 92LSWICH1401AT J AC Switch,Key Type [Enter]
SWB101 QSW-P9005AWZZ J AD Switch,Push Type[Disc Detect 1]
SWB102 QSW-P9005AWZZ J AD Switch,Push Type[Disc Detect 2]
SWB103 QSW-P9005AWZZ J AD Switch,Push Type[Disc Detect 3]
SWB104 QSW-P9003AWZZ J AD Switch,Push Type [Mode 1]
SWB105 QSW-P9003AWZZ J AD Switch,Push Type [Mode 2]
SWB106 QSW-P9003AWZZ J AD Switch,Push Type [Mode 3]
SWB107 QSW-P9003AWZZ J AD Switch,Push Type [Mode 4]
SWB108 QSW-P9003AWZZ J AD Switch,Push Type [Mode 5]
SWB109 QSW-P9004AWZZ J AE Switch,Push Type [Tray 1]
SWB110 QSW-P9004AWZZ J AE Switch,Push Type [Tray 2]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0080AWZZ J AC Rail,Guide
304 NSFTM0020AWFW J AD Shaft,Guide
305 92LMCUSN1524A J AD Cushion
! 306 92LHPC1LXASY J BD Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
307 PCUSG0001AWSA J AD Cushion
308 PCUSG0004AWSA J AD Cushion
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
NM1 92LMTR2996CASY J AS Motor with Chassis [Spindle]
NM2 92LMTR1854BASY J AP Motor with Gear [Sled]
NSW1 QSW-F9001AW01 J AD Switch,Push Type [Pickup In]
CHANGER MECHANISM PARTS
101 LCHSM0106AWZZ J AQ Main Base
102 PGIDM0033AWZZ J AH Changer Box,Left
103 PGIDM0034AWZZ J AG Changer Box,Right
104 NGERH0121AWZZ J AC Gear,Stabilizer B
105 PGIDM0035AWZZ J AH Bracket,Stabilizer Gear
106 MLEVP0098AWZZ J AB Lever,Tray Lock
107 MSPRP0040AWFW J AD Spring,Tray Lock Lever
108 GCOVA1317AWZZ J AF Disc Tray 1
109 GCOVA1318AWZZ J AF Disc Tray 2
110 GCOVA1319AWZZ J AF Disc Tray 3
111 GCOVA1320AWZZ J AF Disc Tray 4
112 GCOVA1321AWZZ J AF Disc Tray 5
113 GCOVA1322AWZZ J AF Disc Tray 6
114 LPLTP0010AWZZ J AG Top Plate,Rear
115 MCAMP0009AWZZ J AE Cam,Lift
116 NSFTT0057AWFD J AE Shaft,Lift Cam
117 LPLTP0009AWZZ J AH Top Plate,Front
118 MLEVP0099AWZZ J AB Lever,Disc OB
119 NGERH0098AWZZ J AC Gear,Stabilizer Drive,Left/Right
120 NGERH0099AWZZ J AC Gear,Stabilizer Drive,Left
121 MLEVF0055AWFW J Lever,OS,Left/Right
122 NGERH0100AWZZ J AC Gear,Stabilizer Drive,Right
123 MSPRT0040AWFJ J AB Spring,OS Lever
124 NGERH0111AWZZ J AC Gear,Tray Drive,Rear
125 NGERH0113AWZZ J AF Gear,Tray Joint,Rear
126 NGERH0116AWZZ J AH Gear,Mode Big
127 NGERH0117AWZZ J AC Gear,Lift A
128 NGERH0118AWZZ J AB Gear,Lift B
129 NGERH0119AWZZ J AF Gear,Lift C
130 NGERH0115AWZZ J AC Gear,Tray Idler
131 NGERH0106AWZZ J AC Gear,Motor Idler,F
132 NGERH0120AWZZ J AB Gear,Stabilizer A
133 NSFTT0055AWM1 J AH Stabilizer Gear Ass’y
133- 1 NGERH0122AWZZ J Gear,Stabilizer C
133- 2 NSFTT0055AWFD J Shaft,Stabilizer Gear
133- 3 NGERH0123AWZZ J Gear,Stabilizer D
134 NGERH0108AWZZ J AK Gear,Tray Big
135 NGERH0109AWZZ J AB Gear,Tray A
136 NGERH0110AWZZ J AC Gear,Tray B
137 NGERH0103AWZZ J AB Gear,Motor Idler,C
138 NGERH0102AWZZ J AC Gear,Motor Idler,B
139 NGERH0105AWZZ J AB Gear,Motor Idler,E
140 NGERH0104AWZZ J AB Gear,Motor Idler,D
141 NGERH0101AWZZ J AD Gear,Motor Idler,A
142 NGERH0114AWZZ J AB Gear,Tray C
143 NGERH0107AWZZ J AC Gear,Tray Drive,Front
144 NGERH0112AWZZ J AF Gear,Tray Joint,Front
145 MLEVP0097AWZZ J AB Lever,Left
146 NSFTT0056AWFD J AC Shaft,Lift Lever
147 LHLDZ1270AWZZ J AH Holder,Stabilizer
148 PMAGF0001AWZZ J AF Magnet
149 LHLDM1011AWZZ J AD Stabilizer
150 92LNBAND1318A J AA Nylon Band,80mm
151 QCNCW025DAWZZ J AB Holder,Flat Wire,4Pin
152 QCNCW025HAWZZ J AC Holder,Flat Wire,8Pin
801 XBPSD26P04000 J AA Screw,ø2.6×4mm
802 XEBSD20P07000 J AB Screw,ø2×7mm
803 XEBSD20P10000 J AA Screw,ø2×10mm
804 XHBSD20P05000 J AA Screw,ø2×5mm
805 LX-EZ0005AWFD J AA Screw,ø2.6×10mm
806 LX-EZ0026AWFD J Screw,ø2×9mm
807 LX-JZ0105AFFN J AA Screw,ø1.7×5mm
808 XEBSD30P10000 J AA Screw,ø3×10mm
MOB1 92LMTR3435DASY J AM Main Cam Motor Ass’y
MOB2 92LMTR3435DASY J AM Tray Motor Ass’y
CABINET PARTS
201 92LCAB3435AASY J Front Panel Ass’y
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 GCOVA1314AWSA J AF Cover,Changer Door Panel,
Bottom
201- 3 GCOVA1315AWSA J AL Cover,Cassette Holder
201- 4 GDORF0080AWSA J AG Cassette Holder
201- 5 GDORF0081AWSA J AD Door,Changer 1
201- 6 GDORF0084AWSA J AD Door,Changer 2
201- 7 GDORF0085AWSA J AD Door,Changer 3
201- 8 GDORF0086AWSA J AD Door,Changer 4
201- 9 GDORF0087AWSA J AD Door,Changer 5
201-10 GDORF0088AWSA J AD Door,Changer 6
201-11 HDECQ0597AWSA J AK Panel,Changer Door
201-12 HDECQ0598AWSA J AN Center Window
201-13 MLOKC0005AWZZ J AC Cassette Lock
201-14 JKNBZ0724AWSA J AF Button,Power
201-15 JKNBZ0726AWSA J AG Button,CD Play
201-16 JKNBZ0735AWSA J AF Button,Control Eject
201-17 JKNBZ0741AWSA J AK Button,CD Eject
201-18 LANGK0210AWFW J AB Bracket,Headphones Support
201-19 LHLDS1005AWZZ J AC Holder,Saft,Left
201-20 LHLDS1006AWZZ J AC Holder,Saft,Right
201-21 LHLDZ1271AWSA J AD Holder,Changer Door
201-22 LHLDZ1276AWZZ J AC Holder,Cassette Lock
201-23 MLIFP0008AWZZ J AD Damper
201-24 MSPRC0029AWFJ J AB Spring,Cassette Lock
201-25 MSPRD0140AWFJ J AC Spring,Cassette Up
201-26 MSPRD0141AWFJ J AB Spring,Changer Door
201-27 PCOVA1323AWSA J AB Cover,Remote Sensor
201-28 PCUSG0053AWSA J AB Cushion,Center Panel
201-29 LHLDZ1272AWZZ J AC Holder,Switch
201-30 PSHEM0010AWZZ J Shield Sheet,Tape Head
201-31 PSHEM0009AWZZ J Earth Sheet,Display PWB
To Next Page
