PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-CH1000
– 3 –
C509,510 RC-GZA106AF1H J AB 10 µF,50V,Electrolytic
C511~514 RC-QZA104AFYJ J AC 0.1 µF,50V,Mylar
C515,516 RC-QZA272AFYJ J AB 0.0027 µF,50V,Mylar
C517~528 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C529,530 RC-GZA106AF1H J AB 10 µF,50V,Electrolytic
C531,532 VCCCCY1HH101J J AA 100 pF (CH),50V
C533,534 VCCCCY1HH470J J AA 47 pF (CH),50V
C535 VCKYCY1EF104Z J AA 0.1 µF,25V
C536 RC-GZA106AF1H J AB 10 µF,50V,Electrolytic
C537 VCKYCY1EF104Z J AA 0.1 µF,25V
C540,541 VCKYCY1HB391K J AA 390 pF,50V
C550,551 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C562 VCKYCY1EF104Z J AA 0.1 µF,25V
C563 RC-GZA106AF1H J AB 10 µF,50V,Electrolytic
C564 VCKYCY1EF104Z J AA 0.1 µF,25V
C566 RC-GZA226AF1H J AB 22 µF,50V,Electrolytic
C573,574 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C597,598 VCKYCY1HB272K J AA 0.0027 µF,50V
C599 VCKYCY1HB102K J AA 0.001 µF,50V
C703 VCTYBT1EF223Z J AA 0.022 µF,25V
C704,705 VCCSPA1HL100J J AA 10 pF,50V
C706 VCKYPA1HF223Z J AB 0.022 µF,50V
C707 VCKYBT1HB101K J AA 100 pF,50V
C708 VCTYBT1EF223Z J AA 0.022 µF,25V
C709 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C712 VCKYBT1HB102K J AA 0.001 µF,50V
C713 VCKYPA1HB102K J AA 0.001 µF,50V
C714 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C715 VCTYPA1CX104K J AB 0.1 µF,16V
C716 VCEAEA1HW225M J AB 2.2 µF,50V,Electrolytic
C807 RC-QZA473AFYJ J AB 0.047 µF,50V,Mylar
C810 RC-GZA226AF1H J AB 22 µF,50V,Electrolytic
C814 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C815,816 VCFYHA1HA104J J AB 0.1 µF,50V,Thin Film
C817 VCEAZW1EW688M J AL 6800 µF,25V,Electrolytic
C819 VCEAZV1EW477M J 470 µF,25V,Electrolytic
C820 RC-QZA473AFYJ J AB 0.047 µF,50V,Mylar
C821 RC-GZA107AF1E J AB 100 µF,25V,Electrolytic
C822 RC-GZA106AF1H J AB 10 µF,50V,Electrolytic
C823 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C824 RC-QZA473AFYJ J AB 0.047 µF,50V,Mylar
C825 RC-GZA108AF0J J AC 1000 µF,6.3V,Electrolytic
C826,827 RC-QZA473AFYJ J AB 0.047 µF,50V,Mylar
C830 VCEAZV1VW477M J AD 470 µF,35V,Electrolytic
C831~835 RC-QZA473AFYJ J AB 0.047 µF,50V,Mylar
! C836 RC-KZ002LAWZZ J AE 0.0047 µF,250V,Ceramic
C837 VCKYPA1HF223Z J AB 0.022 µF,50V
C838 RC-GZA227AF1C J AB 220 µF,16V,Electrolytic
C839 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C840 VCKYPA1HF223Z J AB 0.022 µF,50V
C901 RC-GZA108AF0J J AC 1000 µF,6.3V,Electrolytic
C902 VCKYCY1EF104Z J AA 0.1 µF,25V
C903 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C904 VCKYCY1HB103K J AA 0.01 µF,50V
C905 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C906 VCKYCY1EF104Z J AA 0.1 µF,25V
C907 RC-GZA106AF1H J AB 10 µF,50V,Electrolytic
C912 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C913 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C914 VCKYCY1EF104Z J AA 0.1 µF,25V
C916,917 VCKYCY1EF104Z J AA 0.1 µF,25V
C925,926 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C936 VCCCCY1HH101J J AA 100 pF (CH),50V
C941 VCCCCY1HH220J J AA 22 pF (CH),50V
C942 VCCCCY1HH180J J AA 18 pF (CH),50V
C943 VCKYCY1EF104Z J AA 0.1 µF,25V
C945 VCKYCY1EF104Z J AA 0.1 µF,25V
C950 VCCCCY1HH151J J AA 150 pF (CH),50V
C957 VCCCCY1HH151J J AA 150 pF (CH),50V
C958 VCKYCY1HB391K J AA 390 pF,50V
C964 VCTYPA1HF104Z J AB 0.1 µF,50V
C970 VCKYCY1EF104Z J AA 0.1 µF,25V
C974 VCKYCY1EF104Z J AA 0.1 µF,25V
C975 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C976 VCKYCY1EF104Z J AA 0.1 µF,25V
C977,978 VCCCCY1HH101J J AA 100 pF (CH),50V
C995 VCCCCY1HH101J J AA 100 pF (CH),50V
C998 RC-GZA226AF1A J AB 22 µF,10V,Electrolytic
C999 VCKYCY1HB681K J AA 680 pF,50V
C1001,1002 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C1003 RC-GZA476AF1H J AB 47 µF,50V,Electrolytic
C1004,1005 VCKYCY1EF104Z J AA 0.1 µF,25V
C1006 RC-GZA476AF1H J AB 47 µF,50V,Electrolytic
C1007,1008 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
RESISTORS
VRD-MN2BD000C J AA 0 ohm,Jumper,ø1.4×3.5mm,Ivory
VRS-CY1JB000J J AA 0
ohm,Jumper,0.8×1.55mm,Green
! FR213,214 VRG-ST2EC101J J AB 100 ohm,1/4W,Fusible
! FR251,252 VRG-ST2EC101J J AB 100 ohm,1/4W,Fusible
R6 VRD-ST2EE121J J AA 120 ohms,1/4W
R7~13 VRD-MN2BD102J J AA 1 kohm,1/8W
R14 VRD-ST2CD820J J AA 82 ohms,1/6W
R16 VRD-MN2BD101J J AA 100 ohm,1/8W
R17 VRD-MN2BD102J J AA 1 kohm,1/8W
R18 VRD-MN2BD101J J AA 100 ohm,1/8W
R19 VRD-MN2BD105J J AA 1 Mohm,1/8W
R21 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R25 VRD-MN2BD562J J AA 5.6 kohms,1/8W
R27 VRD-ST2CD473J J AA 47 kohms,1/6W
R28 VRD-MN2BD473J J AA 47 kohms,1/8W
R29 VRD-MN2BD104J J AA 100 kohm,1/8W
R30 VRD-MN2BD225J J AA 2.2 Mohms,1/8W
R31 VRD-MN2BD103J J AA 10 kohm,1/8W
R32 VRD-MN2BD153J J AA 15 kohms,1/8W
R35 VRD-MN2BD102J J AA 1 kohm,1/8W
R36 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R37 VRD-MN2BD333J J AA 33 kohms,1/8W
R38 VRD-ST2CD102J J AA 1 kohm,1/6W
R39 VRD-MN2BD103J J AA 10 kohm,1/8W
R40 VRD-MN2BD101J J AA 100 ohm,1/8W
R41 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R42 VRD-MN2BD563J J AA 56 kohms,1/8W
R43 VRD-MN2BD821J J AA 820 ohms,1/8W
R44 VRD-MN2BD683J J AA 68 kohms,1/8W
R45 VRD-MN2BD822J J AA 8.2 kohms,1/8W
R46 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R47 VRD-MN2BD103J J AA 10 kohm,1/8W
R48 VRD-ST2EE100J J AA 10 ohm,1/4W
R49,50 VRD-ST2CD122J J AA 1.2 kohms,1/6W
R52 VRD-MN2BD561J J AA 560 ohms,1/8W
R53 VRD-MN2BD683J J AA 68 kohms,1/8W
R54 VRD-MN2BD473J J AA 47 kohms,1/8W
R55,56 VRD-MN2BD683J J AA 68 kohms,1/8W
R57 VRD-MN2BD473J J AA 47 kohms,1/8W
R71,72 VRD-MN2BD103J J AA 10 kohm,1/8W
R73,74 VRD-MN2BD822J J AA 8.2 kohms,1/8W
R75,76 VRD-ST2CD103J J AA 10 kohm,1/6W
R77,78 VRD-MN2BD822J J AA 8.2 kohms,1/8W
R91,92 VRD-MN2BD473J J AA 47 kohms,1/8W
R101 VRD-ST2CD102J J AA 1 kohm,1/6W
R102,103 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R104 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R105 VRD-ST2CD101J J AA 100 ohm,1/6W
R109 VRD-ST2CD153J J AA 15 kohms,1/6W
R114,115 VRD-ST2CD102J J AA 1 kohm,1/6W
R116,117 VRD-ST2CD560J J AA 56 ohms,1/6W
R118,119 VRD-ST2CD104J J AA 100 kohm,1/6W
R120,121 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R124,125 VRD-ST2CD562J J AA 5.6 kohms,1/6W
R126,127 VRD-ST2CD153J J AA 15 kohms,1/6W
R128 VRD-ST2CD683J J AA 68 kohms,1/6W
R129,130 VRD-ST2CD102J J AA 1 kohm,1/6W
R131 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R132,133 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R134,135 VRD-ST2CD101J J AA 100 ohm,1/6W
R136~138 VRD-ST2CD103J J AA 10 kohm,1/6W
R139 VRD-ST2CD223J J AA 22 kohms,1/6W
R141 VRD-ST2CD473J J AA 47 kohms,1/6W
R143 VRD-ST2EE820J J AA 82 ohms,1/4W
R144 VRD-ST2EE221J J AA 220 ohms,1/4W
R147 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R148 VRD-ST2CD4R7J J AA 4.7 ohms,1/6W
R149 VRD-ST2CD153J J AA 15 kohms,1/6W
R150 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R153,154 VRD-ST2CD473J J AA 47 kohms,1/6W
R155,156 VRD-ST2CD333J J AA 33 kohms,1/6W
R200 VRD-ST2EE101J J AA 100 ohm,1/4W
R201,202 VRD-ST2CD102J J AA 1 kohm,1/6W
R203,204 VRD-ST2CD821J J AA 820 ohms,1/6W
R205,206 VRD-ST2CD563J J AA 56 kohms,1/6W
R207 VRD-RT2HD120J J AA 12 ohms,1/2W
R209,210 VRD-ST2CD102J J AA 1 kohm,1/6W
