Sharp CD-DVD500 - Speaker Disassembly Details; CP-DVD500 Speaker Disassembly

CD-DVD500
– 14 –
Figure 14-2
Figure 14-5
Figure 14-1
(C1) x 2
ø 3 x 10mm
Woofer
Subwoofer
Tweeter
(A2) x 4
ø 4 x 16mm
(B1) x 4
ø 4 x 16mm
1 Subwoofer 1. Front Panel ............ (A1) x1 14-4
2. Screw ..................... (A2) x4 14-5
2 Woofer 1. Screw ..................... (B1) x4 14-5
3 Tweeter 1. Screw ..................... (C1) x2 14-5
STEP
REMOVAL PROCEDURE
FIGURE
Figure 14-4
CP-DVD500
Screwdriver
Driver should
be pried away
from Speaker Box.
(A1) x 1
Speaker Box
(Q3) x 2
(Q2) x 3
Joint PWB
Slide
Chassis
(Q1) x 2
ø3 x 8mm
DVD
Mechanism
(R2) x 3
(R1) x 1
(R1) x 1
(S1) x 6
DVD Loading
Motor PWB
Figure 14-3
