CD-ES900/CD-ES99
1 – 1
CD-ES900/CD-ES99CD-ES900/CD-ES99Service ManualCD-ES900/CD-ES99MarketE
CHAPTER 1. GENERAL DESCRIPTION
[1] Specifications
General
Amplifier
CD player
Tuner
Cassette deck
Power source AC 120 V, 60 Hz
Power consump-
tion
175 W
Dimensions Width: 10-1/4" (260 mm)
Height: 13" (330 mm)
Depth: 12-7/8" (326 mm)
Weight 22.1 lbs. (10.0 kg)
Output power 200 watts minimum RMS per channel into 6
ohms from 100 Hz to 20 kHz, 10% total har-
monic distortion
Output terminals Speakers: 6 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Video output: 1Vp-p
Input terminals Game/Auxiliary (audio signal):
500 mV/47 k ohms
Game/Video: 1Vp-p
Type 5-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency re-
sponse
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency range FM: 87.5 - 108.0 MHz
AM: 530 - 1,720 kHz
Frequency re-
sponse
50 - 14,000 Hz (normal tape)
Signal/noise ratio 55 dB (TAPE-1 playback)
50 dB (TAPE-2 recording/playback)
Wow and flutter 0.3 % (WRMS)
Type 3-way type speaker system
with passive radiator
Super tweeter x 2
2" (5 cm) tweeter x 1
6-1/2" (16 cm) woofer x 1
4" (10 cm) passive radiator
Maximum input
power
400 W
Rated input power 200 W
Impedance 6 ohms
Dimensions Width: 10-7/8" (277 mm)
Height: 13" (330 mm)
Depth: 11" (279 mm)
Weight 10.6 lbs. (4.8 kg)/each
CD-ES900/CD-ES99
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
CP-ES900/CP-ES99
Specifications for this model are subject to change without
prior notice.
