Sharp CD-K7000W User Manual

– 3 –
CD-K7000W/C7000W,CP-C7000
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
General
Power source: AC 110/127/220/230-240 V,
50/60 Hz
Power consumption: 210 W
Dimensions: Width; 270 mm (10-5/8")
Height; 330 mm (13")
Depth; 355 mm (14")
Weight: 11.5 kg (25.3 lbs.)
Amplifier section
Output power: MPO; 830 W (415 W + 415 W)
(10 % T.H.D.)
RMS; 500 W (250 W + 250 W)
(10 % T.H.D.)
RMS; 440 W (220 W + 220 W)
(0.9 % T.H.D.)
Output terminals: Speakers; 6 ohms
Headphones; 16-50 ohms
(recommended; 32 ohms)
CD digital output (optical)
Input terminals: Video/Auxiliary (audio signal);
(CD-K7000W) 500 mV/47 kohms
Microphone 1/2; 1 mV/
600 ohms
Input terminals: Video/Auxiliary (audio signal);
(CD-C7000W) 500 mV/47 kohms
Compact disc player section
Type: 3-disc multi-play compact disc
player
Signal readout: Non-contact, 3-beam semi-
conductor laser pickup
D/A Converter: 1-bit D/A converter
Frequency response: 20 - 20,000 Hz
Dynamic range: 90 dB (1 kHz)
Specifications for this model are subject to change without
prior notice.
SPECIFICATIONS
Tuner section
Frequency range: FM; 88 - 108 MHz
AM; 531 - 1,602 kHz
Cassette deck section
Frequency response: 50 - 14,000 Hz (Normal tape)
Signal/noise ratio: 55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/
playback)
Wow and flutter: 0.3 % (WRMS)
Speaker section
Type: 4-way type [25 cm (10")woofer,
10 cm (4") midrange, 10 cm (4")
tweeter and super tweeter]
Maximum input power
(Total): 500 W
Rated input power
(Total): 250W
Impedance: 6 ohms
Dimensions: (Main speaker)
Width; 330 mm (13")
Height; 330 mm (13")
Depth; 386 mm (15-3/8")
(Sub speaker)
Width; 330 mm (13")
Height; 135 mm (5-5/16")
Depth; 306 mm (12-1/4")
Weight: (Main speaker)
8.8 kg (19.4 lbs.)/each
(Sub speaker)
3.8 kg (8.4 lbs.)/each
CP-C7000
CD-K7000W/C7000W

Sharp CD-K7000W Specifications

General

Brand	Sharp
Model	CD-K7000W
Category	Stereo System
Language	English
