CD-K7000W/C7000W,CP-C7000
– 6 –
Main speaker
1. Woofer
2. Bass Reflex Duct
3. Speaker Terminals
4. Speaker Wire for Sub Speaker
Remote Control
1. Remote Control Transmitter LED
2. Karaoke Mode Button
3. Vocal Replacer Button
4. Echo Level Up/Down Buttons
5. (CD) Disc Skip Button
6. (CD) Clear Button
7. (CD) Memory Button
8. (CD) Random Button
9. (TAPE 2) Record Pause Button
10. (CD) Track Down/Review Button
(TUNER) Preset Down Button
(TAPE 2) Fast Wind Button
11. (CD) Pause Button
12. (CD) Track Up/Cue Button
(TUNER) Preset Up Button
(TAPE 2) Fast Wind Button
13. Equalizer Mode Selector Button
14. (TAPE 2) Reserve Play Button
15. (CD/TAPE) Stop Button
16. (CD) Play/Repeat Button
(TAPE 1) Play Button
(TAPE 2) Forward Play Button
17. Function Selector Buttons
18. On/Stand-by Button
19. Extra Bass Button
20. Volume Up/Down Buttons
Rear panel
1. AC Voltage Selector
2. AC Power Lead
3. CD Digital Output Socket
4. FM 75 Ohms Aerial Terminal
5. FM Aerial Earth Terminal
6. AM Loop Aerial Input Socket
7. Span Selector Switch
8. Video/Auxiliary (Audio Signal) Input Sockets
9. Main Speaker Terminals
CP-C7000
Sub speaker
1. Mid Range
2. Super Tweeter
3. Tweeter
4. Speaker Terminals
5. Bass Reflex Duct
6
1
3
4
5
2
7
8
9
1
2
3
4
1
23
45
1
5
678
9
10
11
12
13 14 15 16
17
18
19
20
2
3
4
CD-K7000W
To Next Page
