Sharp CD-K7000W User Manual

PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-K7000W/C7000W,CP-C7000
C635,636 VCKYMN1HB102K J AA 0.001 µF,50V
C637 VCKYPA1HB102K J AA 0.001 µF,50V
C709 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C715 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C716,717 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C719 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C720,721 VCKYBT1HB102K J AA 0.001 µF,50V
C722 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C723 VCCSMN1HL150J J AA 15 pF,50V
C724 VCCSMN1HL180J J AA 18 pF,50V
C725 VCKZPA1HF223Z J AA 0.022 µF,50V
C726 RC-EZD227AF1A J AC 220 µF,10V,Electrolytic
C727 RC-EZD104AF1H J AB 0.1 µF,50V,Electrolytic
C728 VCTYMN1CY103N J AA 0.01 µF,16V
C729 VCEAZA1HW335M J AB 3.3 µF,50V,Electrolytic
C730 VCTYMN1EF223Z J AA 0.022 µF,25V
C731 RC-EZD106AF1H J AB 10 µF,50V,Electrolytic
C732 VCKZPA1HF223Z J AA 0.022 µF,50V
C733 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C734 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C735 VCTYMN1EF223Z J AA 0.022 µF,25V
C736 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C737 VCTYMN1EF223Z J AA 0.022 µF,25V
C801 RC-KZ002LAWZZ J AE 0.0047 µF,250V,Ceramic
C802 VCQYKA1HM473J J AB 0.047 µF,50V,Mylar
C803 VCEAZV1VW477M J AD 470 µF,35V,Electrolytic
C804 VCEAZA1CW106M J AC 10 µF,16V,Electrolytic
C805 VCEAZV0JW228M J AC 2200 µF,6.3V,Electrolytic
C809,810 VCFYDA1HA224J J AB 0.22 µF,50V,Polyester
C811,812 VCQYKU2AM224K J AB 0.22 µF,100V,Mylar
C813,814 VCFYDA1HA224J J AB 0.22 µF,50V,Polyester
C815,816 VCEAZA1HW107M J AC 100 µF,50V,Electrolytic
C817 VCEAZV1JW227M J AC 220 µF,63V,Electrolytic
C818,819 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C820 VCEAZA1VW107M J AC 100 µF,35V,Electrolytic
C821 VCEAZV1JW107M J 100 µF,63V,Electrolytic
C850 VCEAZW1EW338M J AG 3300 µF,25V,Electrolytic
C851 VCEAZA1EW226M J AB 22 µF,25V,Electrolytic
C852 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C855,856 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C857 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C858,859 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C860 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C861,862 VCTYMN1EF223Z J AA 0.022 µF,25V
C863,864 VCEAZA1EW226M J AB 22 µF,25V,Electrolytic
C865 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C901,902 VCEAZW2AW338M J 3300 µF,100V,Electrolytic
C903,904 RC-GZW478AF1H J AH 4700 µF,50V,Electrolytic
C911,912 VCCSPA1HL221J J AA 220 pF,50V
C913,914 VCCSPA1HL470J J AA 47 pF,50V
C915,916 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C917,918 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C919,920 VCEAZV2AW107M J 100 µF,100V,Electrolytic
C921,922 VCEAZA1HW107M J AC 100 µF,50V,Electrolytic
C923,924 VCQYKA1HM223J J AB 0.022 µF,50V,Mylar
C925 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C927~930 VCFYHA1HA224J J AC 0.22 µF,50V,Thin Film
C931~938 VCQYKA1HM223J J AB 0.022 µF,50V,Mylar
C943 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C945 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C946 VCEAZA0JW107M J AC 100 µF,6.3V,Electrolytic
C951 VCQYKA1HM223J J AB 0.022 µF,50V,Mylar
C952 VCEAZA1EW227M J AC 220 µF,25V,Electrolytic
C957 VCEAZV2AW107M J 100 µF,100V,Electrolytic
CK1 VCTYPA1CX103K J AA 0.01 µF,16V [CD-K7000W Only]
CK2 VCFYHA1HA474J J AD 0.47 µF,50V,Thin Film
[CD-K7000W Only]
CK3 RC-EZY475AF1H J AB 4.7 µF,50V,Electrolytic
[CD-K7000W Only]
CK4 RC-EZY225AF1H J AB 2.2 µF,50V,Electrolytic
[CD-K7000W Only]
CK5,6 VCFYDA1HA104J J AB 0.1 µF,50V,Thin Film
[CD-K7000W Only]
CK7 VCFYHA1HA474J J AD 0.47 µF,50V,Thin Film
[CD-K7000W Only]
CK8 RC-EZY475AF1H J AB 4.7 µF,50V,Electrolytic
[CD-K7000W Only]
CK9 RC-EZY225AF1H J AB 2.2 µF,50V,Electrolytic
[CD-K7000W Only]
CK10,11 VCFYDA1HA104J J AB 0.1 µF,50V,Thin Film
[CD-K7000W Only]
CK12 RC-EZY225AF1H J AB 2.2 µF,50V,Electrolytic
[CD-K7000W Only]
CK13 VCTYPA1CX472K J AA 0.0047 µF,16V
[CD-K7000W Only]
CK14 VCTYPA1CX102K J AA 0.001 µF,16V
[CD-K7000W Only]
CK15 VCQYKA1HM683K J AB 0.068 µF,50V,Mylar
[CD-K7000W Only]
CK16 VCFYHA1HA224J J AC 0.22 µF,50V,Thin Film
[CD-K7000W Only]
CK17 VCEAZA1AW227M J AC 220 µF,10V,Electrolytic
[CD-K7000W Only]
CK18 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
[CD-K7000W Only]
CK19 VCKZPA1HF223Z J AA 0.022 µF,50V
[CD-K7000W Only]
CK20 VCFYHA1HA224J J AC 0.22 µF,50V,Thin Film
[CD-K7000W Only]
CK21 VCQYKA1HM683K J AB 0.068 µF,50V,Mylar
[CD-K7000W Only]
CK22 VCTYPA1CX472K J AA 0.0047 µF,16V
[CD-K7000W Only]
CK23 VCTYPA1CX102K J AA 0.001 µF,16V
[CD-K7000W Only]
CK24~26 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
[CD-K7000W Only]
CK29,30 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
[CD-K7000W Only]
CK31 VCFYDA1HA154J J AB 0.15 µF,50V,Polyester
[CD-K7000W Only]
CK33~35 VCCSPA1HL470J J AA 47 pF,50V [CD-K7000W Only]
CK41 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
[CD-K7000W Only]
CK42 VCKZPA1HF223Z J AA 0.022 µF,50V
[CD-K7000W Only]
CK43,44 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
[CD-K7000W Only]
CK72 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
[CD-K7000W Only]
CK73,74 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
[CD-K7000W Only]
RESISTORS
VRD-MN2BD000C J AA 0 ohm,Jumper,ø1.4×3.5mm,Ivory
VRS-TV2AB000J J AA 0 ohm,Jumper,1.25×2mm,Green
R3 VRS-TV2AB473J J AA 47 kohms,1/10W
R4 VRS-TV2AB103J J AA 10 kohm,1/10W
R5 VRS-TV2AB393J J AA 39 kohms,1/10W
R6 VRS-TV2AB273J J AA 27 kohms,1/10W
R7 VRS-TV2AB682J J AA 6.8 kohms,1/10W
R8 VRS-TV2AB331J J AA 330 ohms,1/10W
R10 VRS-TV2AB273J J AA 27 kohms,1/10W
R11 VRS-TV2AB123J J AA 12 kohms,1/10W
R12,13 VRS-TV2AB681J J AA 680 ohms,1/10W
R14 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R15 VRS-TV2AB103J J AA 10 kohm,1/10W
R16 VRD-ST2CD103J J AA 10 kohm,1/6W
R17 VRD-ST2CD102J J AA 1 kohm,1/6W
R19 VRD-ST2CD470J J AA 47 ohms,1/6W
R20 VRS-TV2AB221J J AA 220 ohms,1/10W
R21,22 VRS-TV2AB471J J AA 470 ohms,1/10W
R25 VRD-ST2CD103J J AA 10 kohm,1/6W
R35 VRD-ST2CD102J J AA 1 kohm,1/6W
R38 VRD-ST2CD271J J AA 270 ohms,1/6W
R39 VRD-ST2CD471J J AA 470 ohms,1/6W
R40 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R42 VRS-TV2AB124J J AA 120 kohms,1/10W
R44 VRD-ST2CD102J J AA 1 kohm,1/6W
R45 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R46 VRS-TV2AB102J J AA 1 kohm,1/10W
R47 VRD-ST2EE3R3J J AA 3.3 ohms,1/4W
R48 VRS-TV2AB682J J AA 6.8 kohms,1/10W
R50 VRS-TV2AB470J J AA 47 ohms,1/10W
R51~54 VRS-TV2AB683J J AA 68 kohms,1/10W
R55,56 VRD-ST2CD683J J AA 68 kohms,1/6W
R58 VRD-ST2CD221J J AA 220 ohms,1/6W
R67,68 VRD-ST2CD102J J AA 1 kohm,1/6W
R71~78 VRD-ST2CD102J J AA 1 kohm,1/6W
R79 VRS-TV2AB155J J AA 1.5 Mohms,1/10W
R80 VRD-ST2CD105J J AA 1 Mohm,1/6W
R81,82 VRS-TV2AB222J J AA 2.2 kohms,1/10W
– 3 –
