Sharp CD-K7000W User Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-K7000W/C7000W,CP-C7000
CNP12 92LCONEAP53254 J AD Plug,10Pin
CNP101 QCNCM705CAFZZ J AA Plug,3Pin
CNP301 92LCONE2P5268 J AB Plug,2Pin
CNP601 92LCONEBP53253 J AC Plug,11Pin [CD-K7000W Only]
CNP701 QCNCWZX30AWZZ J Socket,30Pin
CNP704 92LCONE5P53254 J AB Plug,5Pin
CNP801 QCNCM051EAWZZ J AD Plug,5Pin
CNP802 92LCONE5P5267X J AB Plug,5Pin
CNP803 QCNCM049EAWZZ J AD Plug,5Pin
CNP901 QCNCM010TAWZZ J AD Plug,18Pin
CNP903 92LCONE2P53253 J AB Plug,2Pin
CNS1A/B QCNWN1537AWZZ J AG Connector Ass’y,7/7Pin
CNS2A/B QCNWN1538AWZZ J AG Connector Ass’y,8/8Pin
CNS3A/B QCNWN1539AWZZ J AE Connector Ass’y,6/6Pin
CNS701 QCNCWZF30AWZZ J Socket,30Pin
CNS702 QCNCWZY13AWZZ J AC Plug,13Pin
CNS901 QCNCW010TAWZZ J AE Socket,18Pin
CNS903 QCNWN1582AWZZ J Connector Ass’y,2Pin
! F801 92LFUSET632E J AD Fuse,T6.3A L 250V
! F802,803 92LFUSET312E J AD Fuse,T3.15A L 250V
! F804,805 92LFUSET632E J AD Fuse,T6.3A L 250V
! F806 92LFUSET202E J Fuse,T2A L 250V
FFC701 QCNWN1581AWZZ J Flat Cable,30Pin
FFC702 QCNWN1544AWZZ J AE Flat Cable,13Pin
FL701 VVKBJ744GNK-1 J BD FL Display
FW902 QCNWN1577AWZZ J Flat Wire,5Pin
JK1 QJAKJ0007AWZZ J AF Jack,Mic 1
JK2 QJAKJ0007AWZZ J AF Jack,Mic 2
JK601 QSOCJ0213AWZZ J AE Jack,Video In
JK670 QJAKM0010AWZZ J AF Jack,Headphones
JOG701 QSW-Z0010AWZZ J AF Switch,Rotary Type [JOG]
! K801,802 92LLUG1746A J AA Lug,Terminal
LG901 QLUGP0001AWZZ J AC Lug
LUG1 QLUGP0002AWZZ J AB Lug
M1 92LMTR2790CASY J BB Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
M3 92LTWMEN7E6Y J AR Motor with Worm Pulley
[T/T Up/Down Loading]
M701 RMOTV0027AWZZ J AM Motor,Volume
M901 RMOTV0027AWZZ J AM Motor,Air Cooling Fan
PIN103 QLUGP0002AWZZ J AB Lug
PINK1 QLUGP0002AWZZ J AB Lug
RL801 RRLYD0012AWZZ J AM Relay
RL901 RRLYD0004AWZZ J AP Relay
RX701 VHLN63H380A-1 J AK Remote Sensor,N63H380A
SO302 QTANC0204AWZZ J FM Antenna Terminal
SO901 QTANA0401AWZZ J AG Terminal,Speaker
SW1 SWMPU10780MLB J Switch,Push Type [Open/Close]
SW2 SWMPU11470MLB J Switch,Push Type [Clamp]
SW3 SWMPU11470MLB J Switch,Push Type [Disc Number]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
SW601 QSW-S0024AWZZ J AE Switch,Slide Type
[SPAN SELECTOR]
SW701 92LSWICHT1663T J AC Switch,Key Type
[ON/STAND-BY]
SW702 92LSWICHT1663T J AC Switch,Key Type [CLOCK]
SW703 92LSWICHT1663T J AC Switch,Key Type
[TIMER/SLEEP]
SW709 92LSWICHT1663T J AC Switch,Key Type [DISC 1]
SW710 92LSWICHT1663T J AC Switch,Key Type [DISC 2]
SW711 92LSWICHT1663T J AC Switch,Key Type [DISC 3]
SW712 92LSWICHT1663T J AC Switch,Key Type [DISC SKIP]
SW713 92LSWICHT1663T J AC Switch,Key Type
[OPEN/CLOSE]
SW714 92LSWICHT1663T J AC Switch,Key Type [DIMMER]
SW715 92LSWICHT1663T J AC Switch,Key Type
[X-BASS/DEMO]
SW716 92LSWICHT1663T J AC Switch,Key Type [EQUALIZER]
SW717 92LSWICHT1663T J AC Switch,Key Type [SURROUND]
SW718 92LSWICHT1663T J AC Switch,Key Type [REV MODE]
SW719 92LSWICHT1663T J AC Switch,Key Type [CD]
SW723 92LSWICHT1663T J AC Switch,Key Type [TAPE]
SW724 92LSWICHT1663T J AC Switch,Key Type
[TUNING DOWN]
SW725 92LSWICHT1663T J AC Switch,Key Type
[MEMORY/SET]
SW726 92LSWICHT1663T J AC Switch,Key Type
[TRACK DOWN/REVIEW/
PRESET DOWN/REWIND]
SW727 92LSWICHT1663T J AC Switch,Key Type
[TRACK UP/CUE/PRESET UP/
FAST FORWARD]
SW728 92LSWICHT1663T J AC Switch,Key Type [PLAY]
SW729 92LSWICHT1663T J AC Switch,Key Type [STOP]
SW730 92LSWICHT1663T J AC Switch,Key Type
[REVERSE PLAY]
SW731 92LSWICHT1663T J AC Switch,Key Type [REC PAUSE]
SW732 92LSWICHT1663T J AC Switch,Key Type [TUNING UP]
SW733 92LSWICHT1663T J AC Switch,Key Type [VIDEO/AUX]
SW734 92LSWICHT1663T J AC Switch,Key Type
[TUNER (BAND)]
! SW801 QSOCE0008AWZZ J AH Switch,Slide Type
[Voltage Selector]
WT601 QCNCW012EAWZZ J AC Plug,5Pin
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Warm Gear,Drive
303 MLEVP0080AWZZ J AC Rail,Guide
304 NSFTM0020AWFW J AD Shaft,Guide
305 92LM-CUSN1524A J AC Cushion
! 306 92LHPC1LXASY J BD Pickup Unit Ass’y
306- 1 ———— — Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
M1 92LMTR2790CASY J BB Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
CABINET PARTS
201 92LCAB3307AASY J Front Panel Ass’y [CD-C7000W]
201 92LCAB3352AASY J Front Panel Ass’y [CD-K7000W]
201- 1 ———— — Front Panel
(Not Replacement Item)
201- 2 GDORF0074AWSA J AE Holder,Cassette,Tape 1
201- 3 GDORF0075AWSA J AE Holder,Cassette,Tape 2
201- 4 GCOVA1251AWSA J AH Cover,Cassette,Tape 1
201- 5 GCOVA1298AWSA J AE Cover,Cassette,Tape 2
201- 6 HDECQ0521AWSA J AD Panel,Cassette,Tape 1
201- 7 HDECQ0522AWSA J AD Panel,Cassette,Tape 2
201- 8 HDECQ0565AWSA J Panel,Amp. [CD-K7000W]
201- 8 HDECQ0571AWSA J Panel,Amp. [CD-C7000W]
201- 9 HDECQ0566AWSA J Decoration Plate
201-10 JKNBZ0665AWSA J AF Knob,Disc Control
201-11 JKNBZ0683AWSA J AG Knob,Center Operation
201-12 JKNBZ0714AWSA J AF Knob,ON/Stand-by/Clock
201-13 JKNBZ0672AWSA J AF Knob,Function,A
201-14 JKNBZ0673AWSA J AF Knob,Function,B
201-15 JKNBZ0660AWSA J AF Knob,Tuning
201-16 JKNBZ0661AWSA J AE Knob,Dimmer
201-17 HDECQ0526AWSA J AE Volume Light Up Ring
201-19 GCOVA1265AWZZ J AC Cover,Function LED Top A
201-20 GCOVA1258AWSA J AB Cover,Power LED
201-21 MLIFP0008AWZZ J AD Damper
201-22 MSPRD0138AWFJ J Spring,Cassette,Tape 1
201-23 MSPRD0127AWFJ J AB Spring,Cassette,Tape 2
201-24 92LBADGE1671A J AC Badge,SHARP
201-25 JKNBZ0710AWSA J AE Knob,Surround
201-26 GCOVA1266AWZZ J AC Cover,Function LED Top B
201-27 GCOVA1267AWZZ J AC Cover,Function LED Top C
201-28 GCOVA1268AWZZ J AC Cover,Function LED Top D
201-29 GCOVA1260AWSA J AB Cover,Control LED Top A
201-30 GCOVA1275AWSA J AB Cover,Control LED Top B
201-31 GCOVA1276AWSA J AB Cover,Control LED Top C
201-32 GCOVA1256AWSA J AB Cover,Preset LED Top
201-33 GCOVA1277AWSA J AB Cover,Operation LED Top A
202 92LCAB3303BASY J Side Panel Ass’y,Left
202- 1 ———— — Side Panel,Left
(Not Replacement Item)
202- 2 PCUSG0022AWZZ J AB Cushion,Leg
203 92LCAB3303CASY J Side Panel Ass’y,Right
203- 1 ———— — Side Panel,Right
(Not Replacement Item)
203- 2 PCUSG0022AWZZ J AB Cushion,Leg
204 92LCOV3303AASY J CD Tray Cover Ass’y
204- 1 ———— — Cover,CD Tray
(Not Replacement Item)
– 6 –

Sharp CD-K7000W Specifications

General

Brand	Sharp
Model	CD-K7000W
Category	Stereo System
Language	English
